The correct answer is D. Newton
Answer:
0.37 m
Explanation:
Let the shoulder be the origin.
The center of mass of the arm bones is 0.60 m/2 = 0.30 m and the center of mass of the hand bones is 0.10 m/2 = 0.05 m since they are modeled as straight rods with uniform density and the center of mass of a rod is x = L/2 where L is the length of the rod.
The center of mass y = (m₁y₁ + m₂y₂)/(m₁ + m₂) where m₁ = mass of arm bones = 4.0 kg, y₁ = distance center of mass of arm bones from shoulder = 0.30 m, m₂ = mass of hand bones = 1.0 kg and y₂ = distance of center of mass hand bones from shoulder = x₁ + distance of center of hand bones from wrist = 0.60 m + 0.05 m = 0.65 m
Substituting these into the equation for the center of mass, we have
y = (m₁y₁ + m₂y₂)/(m₁ + m₂)
y = (4.0 kg × 0.30 m + 1.0 kg × 0.65 m)/(4.0 kg + 1.0 kg)
y = (1.20 kgm + 0.65 kgm)/5.0 kg
y = 1.85 kgm/5.0 kg
y = 0.37 m
The distance of the center of mass from the shoulder is thus y = 0.37 m
<span>net work = change in kinetic energy
for Block B, we just have the force from block A acting on it
F(ab)d= .5(1)vf² - .5(1)(2²)
F(ab)d= .5vf² - 2
Block A, we have the force from the hand going in one direction and the force of block B on A going the opposite direction
10-F(ba)d = .5(4)vf² - .5(4)(2²)
10-F(ba)d = 2vf² - 8
F(ba)d = 18 - 2vf²
now we have two equations:
F(ba)d = 18 - 2vf²
F(ab)d= .5vf² - 2
since the magnitude of F(ba) and F(ab) is the same, substitute and find vf (I already took into account the direction when solving for F(ab)
10-.5vf² + 2 = 2vf² - 8
12 - .5vf² = 2vf² - 8
20 = 2.5vf²
vf² = 8
they both will have the same velocity
KE of block A= .5(4)(2.828²) = 16 J
KE of block B=.5(1)(2.828²) = 4 J</span>
Friction causes resistance against a moving object. It can cause an object to slow down, or stop when there’s enough friction…. I hope this helps
