The so-called "velocity-time" graph is actually a "speed-time" graph. At any point
on it, the 'x'-coordinate is a time, and the 'y'-coordinate is the speed at that time.
'Velocity' is a speed AND a direction. Without a direction, you do not have a velocity,
and these graphs never show the direction of the motion. It seems to me that it would be
pretty tough to draw a graph that shows the direction of motion at every instant of time,
so my take is that you'll never see a true "velocity-time" graph.
At best, it would need a second line on it, whose 'y'-coordinate referred to a second
axis, calibrated in angle and representing the 'bearing' or 'heading' of the motion at
each instant. The graph of uniform circular motion, for example, would have a straight
horizontal line for speed, and a 'sawtooth' wave for direction.
Answer:
Time, t = 0.104 seconds
Explanation:
Frequency of the click of the Dolphin, f = 55.3 kHz
A dolphin sends out a series of clicks that are reflected back from the bottom of the ocean 80 m below, d = 80 m
The speed of sound in seawater is, v = 1530 m/s
Once the sound is send and reflects, the total distance covered by it is 2d such that,
So, the time elapses before the dolphin hears the echoes of the clicks is 0.104 seconds.
Idkbjkhfvhkl glgffkkrfkfkfk Goff
Complete question:
A solenoid that is 98.6 cm long has a cross-sectional area of 24.3 cm2. There are 1310 turns of a wire carrying a current of 6.75 A. (a) Calculate the energy density of the magnetic field inside the solenoid. (b) Find the total energy stored in the magnetic field there (neglect end effects).
Answer:
(a) the energy density of the magnetic field inside the solenoid is 50.53 J/m³
(b) the total energy stored in the magnetic field is 0.121 J
Explanation:
Given;
length of the solenoid, L = 98.6 cm = 0.986 m
cross-sectional area of the solenoid, A = 24.3 cm² = 24.3 x 10⁻⁴ m²
number of turns of the solenoid, N = 1310 turns
The magnitude of the magnetic field inside the solenoid is given by;
B = μ₀nI
B = μ₀(N/L)I
Where;
μ₀ is permeability of free space, = 4π x 10⁻⁷ m/A
(a) Calculate the energy density of the magnetic field inside the solenoid
(b) Find the total energy stored in the magnetic field
U = uV
U = u (AL)
U = 50.53 (24.3 x 10⁻⁴ x 0.986)
U = 0.121 J
Answer:
In physics, work is defined as the use of force to move an object. For work to be done, the force must be applied in the same direction that the object moves. Work is directly related to both the force applied to an object and the distance the object moves. <em>[I HOPE THIS HELPS* PLS MARK ME BRAINLIEST]</em>
