What are the factors that influence the power input to the compressor?

What are the relevance of report writing

nasty-shy [4]

Answer:Report writing consists of the history and facts of a project or of any kind of event. It is useful to record past history and an overall summary of decisions. Report writing helps to solve problems as a path. Writing a report will guide you in a way that will modernize details of the improvements and upcoming plans.

6 0

2 years ago

A solid circular rod that is 600 mm long and 20 mm in diameter is subjected to an axial force of P = 50 kN The elongation of the

Kay [80]

Answer:

a) V = 0.354

b) G = 25.34 GPA

Explanation:

Solution:

We first determine Modulus of Elasticity and Modulus of rigidity

Elongation of rod ΔL = 1.4 mm

Normal stress, δ = P/A

Where P = Force acting on the cross-section

A = Area of the cross-section

Using Area, A = π/4 · d²

= π/4 · (0.0020)² = 3.14 × 10⁻⁴m²

δ = 50/3.14 × 10⁻⁴ = 159.155 MPA

E(long) = Δl/l = 1.4/600 = 2.33 × 10⁻³mm/mm

Modulus of Elasticity Е = δ/ε

= 159.155 × 10⁶/2.33 × 10⁻³ = 68.306 GPA

Also final diameter d(f) = 19.9837 mm

Initial diameter d(i) = 20 mm

Poisson said that V = Е(elasticity)/Е(long)

= - <u>( 19.9837 - 20 /20)</u>

2.33 × 10⁻³

= 0.354,

∴ v = 0.354

Also G = Е/2. (1+V)

= 68.306 × 10⁹/ 2.(1+ 0.354)

= 25.34 GPA

⇒ G = 25.34 GPA

5 0

3 years ago

A large plate is fabricated from a steel alloy that has a plane strain fracture toughness of 55 MPa √m (50 ksi √in.). If, during

astra-53 [7]

Answer:

0.024 m = 24.07 mm

Explanation:

1) Notation

$\sigma_c$ = tensile stress = 200 Mpa

$K$ = plane strain fracture toughness= 55 Mpa $\sqrt{m}$

$\lambda$ = length of a surface crack (Variable of interest)

2) Definition and Formulas

The Tensile strength is the ability of a material to withstand a pulling force. It is customarily measured in units (F/A), like the pressure. Is an important concept in engineering, especially in the fields of materials and structural engineering.

By definition we have the following formula for the tensile stress:

$\sigma_c=\frac{K}{Y\sqrt{\pi\lambda}}$ (1)

We are interested on the minimum length of a surface that will lead to a fracture, so we need to solve for $\lambda$

Multiplying both sides of equation (1) by $Y\sqrt{\pi\lambda}$

$\sigma_c Y\sqrt{\pi\lambda}=K$ (2)

Sequaring both sides of equation (2):

$(\sigma_c Y\sqrt{\pi\lambda})^2=(K)^2$

$\sigma^2_c Y^2 \pi\lambda=K^2$ (3)

Dividing both sides by $\sigma^2_c Y^2 \pi$ we got:

$\lambda=\frac{1}{\pi}[\frac{K}{Y\sigma_c}]^2$ (4)

Replacing the values into equation (4) we got:

$\lambda=\frac{1}{\pi}[\frac{55 Mpa\sqrt{m}}{1.0(200Mpa)}]^2 =0.02407m$

3) Final solution

So the minimum length of a surface crack that will lead to fracture, would be 24.07 mm or more.

7 0

3 years ago

An 1,840 W toaster, a 1,420 W electric frying pan, and a 70 W lamp are plugged into the same outlet in a 15 A, 120 V circuit. (T

Viktor [21]

Answer:

A)

Current drawn by toaster = 15.33 A

Current drawn by electric frying pan = 11.83 A

Current drawn by lamp = 0.58 A

B)

The fuse will definitely blow up since the current drawn by three devices (27.74 A) is way higher than 15 A fuse rating.

Explanation:

There are three devices plugged into the same outlet.

Toaster = 1840 W

Electric frying pan = 1420 W

Lamp = 70 W

Since the three devices are connected in parallel therefore, the voltage across them will be same but the current drawn by each will be different.

A) What current is drawn by each device?

The current flowing through the device is given by

I = P/V

Where P is the power and V is the voltage.

Current drawn by toaster:

I = 1840/120

I = 15.33 A

Current drawn by electric frying pan:

I = 1420/120

I = 11.83 A

Current drawn by lamp:

I = 70/120

I = 0.58 A

B) Will this combination blow the 15-A fuse?

The total current drawn by all three devices is

Total current = 15.33 + 11.83 + 0.58

Total current = 27.74 A

Therefore, the fuse will definitely blow up since the current drawn by three devices (27.74 A) is way higher than 15 A fuse rating.

5 0

3 years ago

How will you maintain the orderliness of your storage area 2pts?

fiasKO [112]

Explanation:

Label and group products. One would think that a general cleanup would be the first step, but no, it's not. ...Clean up the area. ...Put up demarcation lines. ...Stack properly. ...Keep the aisles, paths and ramps clear. ...Have all the safety signs in place.

4 0

2 years ago
