Answer and explanation:
The graphical representation of the electronic eye
The state table showing
the present state
input
Next state and
the output
are shown in the attached file
Answer:
The correct option is;
Neither Technician A nor B
Explanation:
The evaporative emission monitor or Evaporaive Emission Control System EVAP System monitors enables the Power Control Module of the car to check fuel system leak integrity and the vapor consumption efficiency during engine combustion
It is a requirement of EPA on cars to check the emission of smug forming evaporates from cars
Serious monitor faults can cause the turning on of the check engine lights and the vehicle will not pass OBD II test, but it will not lead to engine shutdown
It runs when the engine is 15 to 85% full and the TP sensor is between 9% and 35%.
Therefore, the correct option is that neither Technician A nor B are correct.
Answer:
The minimum diameter for each cable should be 0.65 inches.
Explanation:
Since, the load is supported by two ropes and the allowable stress in each rope is 1500 psi. Therefore,
(1/2)(Weight/Cross Sectional Area) = Allowable Stress
Here,
Weight = 1000 lb
Cross-sectional area = πr²
where, r = minimum radius for each cable
(1/2)(1000 lb/πr²) = 1500 psi
500 lb/1500π psi = r²
r = √1.061 in²
r = 0.325 in
Now, for diameter:
Diameter = 2(radius) = 2r
Diameter = 2(0.325 in)
<u>Diameter = 0.65 in</u>
