List two things that technological systems have in common.

1 answer:

3 0

They all share the way that they are fundamentally designed: if they are quite complex, they will share the same basic logic foundations, like the way that the programming languages work. They also all share the method of construction and common and fundamental electronic components, like resistors, capacitors and transistors. As we humans design them, they make logical sense to at least someone, and probably only discounting the internet, you can probably draw logic diagrams and whatever to represent how they work.

Because they are designed by Humans, in a way they all mimic how our brains and society work. Also, as yet there are no truly intelligent technological systems, and are only able to react to a situation how they have been programmed to do so.

You might be interested in

An insulated piston-cylinder device contains 5 L of saturated liquid water at a constant pressure of 175 kPa. Water is stirred b

irinina [24]

Answer:

note:

solution is attached in word form due to error in mathematical equation. furthermore i also attach Screenshot of solution in word due to different version of MS Office please find the attachment

Download docx

4 0

3 years ago

Consider a regenerative gas-turbine power plant with two stages of compression and two stages of expansion. The overall pressure

iris [78.8K]

Answer: the minimum mass flow rate of air required to generate a power output of 105 MW is 238.2 kg/s

Explanation:

from the T-S diagram, we get the overall pressure ratio of the cycle is 9

Calculate the pressure ratio in each stage of compression and expansion. P1/P2 = P4/P3 = √9 = 3

P5/P6 = P7/P8 = √9 =3

get the properties of air from, "TABLE A-17 Ideal-gas properties of air", in the text book.

At temperature T1 =300K

Specific enthalpy of air h1 = 300.19 kJ/kg

Relative pressure pr1 = 1.3860

At temperature T5 = 1200 K

Specific enthalpy h5 = 1277.79 kJ/kg

Relative pressure pr5 = 238

Calculate the relative pressure at state 2

Pr2 = (P2/P1) Pr5

Pr2 =3 x 1.3860 = 4.158

get the two values of relative pressure between which the relative pressure at state 2 lies and take the corresponding values of specific enthalpy from, "TABLE A-17 Ideal-gas properties of air", in the text book.

Relative pressure pr = 4.153

The corresponding specific enthalpy h = 411.12 kJ/kg

Relative pressure pr = 4.522

The corresponding specific enthalpy h = 421.26 kJ/kg

Find the specific enthalpy of state 2 by the method of interpolation

(h2 - 411.12) / ( 421.26 - 411.12) =

(4.158 - 4.153) / (4.522 - 4.153 )

h2 - 411.12 = (421.26 - 411.12) ((4.158 - 4.153) / (4.522 - 4.153))

h2 - 411.12 = 0.137

h2 = 411.257kJ/kg

Calculate the relative pressure at state 6.

Pr6 = (P6/P5) Pr5

Pr6 = 1/3 x 238 = 79.33

Obtain the two values of relative pressure between which the relative pressure at state 6 lies and take the corresponding values of specific enthalpy from, "TABLE A-17 Ideal-gas properties of air", in the text book.

Relative pressure Pr = 75.29

The corresponding specific enthalpy h = 932.93 kJ/kg

Relative pressure pr = 82.05

The corresponding specific enthalpy h = 955.38 kJ/kg

Find the specific enthalpy of state 6 by the method of interpolation.

(h6 - 932.93) / ( 955.38 - 932.93) =

(79.33 - 75.29) / ( 82.05 - 75.29 )

(h6 - 932.93) = ( 955.38 - 932.93) ((79.33 - 75.29) / ( 82.05 - 75.29 )

h6 - 932.93 = 13.427

h6 = 946.357 kJ/kg

Calculate the total work input of the first and second stage compressors

(Wcomp)in = 2(h2 - h1 ) = 2( 411.257 - 300.19 )

= 222.134 kJ/kg

Calculate the total work output of the first and second stage turbines.

(Wturb)out = 2(h5 - h6) = 2( 1277.79 - 946.357 )

= 662.866 kJ/kg

Calculate the net work done

Wnet = (Wturb)out - (Wcomp)in

= 662.866 - 222.134

= 440.732 kJ/kg

Calculate the minimum mass flow rate of air required to generate a power output of 105 MW

W = m × Wnet

(105 x 10³) kW = m(440.732 kJ/kg)

m = (105 x 10³) / 440.732

m = 238.2 kg/s

therefore the minimum mass flow rate of air required to generate a power output of 105 MW is 238.2 kg/s

4 0

3 years ago

The tolerance for a geometric can be easily identified by reading the _________.

baherus [9]

Answer:

Explanation:

4 0

3 years ago

Read 2 more answers

Water is being added to a storage tank at the rate of 500 gal/min. Water also flows out of the bottom through a 2.0-in-inside di

melomori [17]

Answer:

From the answer, the water level is falling (since rate of outflow is more than that of inflow), and the rate at which the water level in the storage tank is falling is

(dh/dt) = - 0.000753

Units of m/s

Explanation:

Let the volume of the system at any time be V.

V = Ah

where A = Cross sectional Area of the storage tank, h = height of water level in the tank

Let the rate of flow of water into the tank be Fᵢ.

Take note that Fᵢ is given in the question as 500 gal/min = 0.0315 m³/s

Let the rate of flow of water out of the storage tank be simply F.

F is given in the form of (cross sectional area of outflow × velocity)

Cross sectional Area of outflow = πr²

r = 2 inches/2 = 1 inch = 0.0254 m

Cross sectional Area of outflow = πr² = π(0.0254)² = 0.00203 m²

velocity of outflow = 60 ft/s = 18.288 m/s

Rate of flow of water from the storage tank = 0.0203 × 18.288 = 0.0371 m³/s

We take an overall volumetric balance for the system

The rate of change of the system's volume = (Rate of flow of water into the storage tank) - (Rate of flow of water out of the storage tank)

(dV/dt) = Fᵢ - F

V = Ah (since A is constant)

dV/dt = (d/dt) (Ah) = A (dh/dt)

dV/dt = A (dh/dt) = Fᵢ - F

Divide through by A

dh/dt = (Fᵢ - F)/A

Fi = 0.0315 m³/s

F = 0.0371 m³/s

A = Cross sectional Area of the storage tank = πD²/4

D = 10 ft = 3.048 m

A = π(3.048)²/4 = 7.30 m²

(dh/dt) = (0.0315 - 0.0370)/7.3 = - 0.000753

(dh/dt) = - 0.000753

4 0

2 years ago

Refer to Figure 9-18. A #_____ electrode lead and workpiece lead should be used to carry 150 amperes of electricity 75 feet to t

Anni [7]

Answer:

AC or

Explanation:

8 0
