<span>The answer is letter C.
Reflecting telescopes are more powerful than refracting telescopes. These are also called as reflectors which serves an optical telescope that uses a single or combination of curved mirrors. These mirrors then reflect light and form an image. It is designed for very large diameter objects and are mostly considered as major telescopes in the field of astronomy. They were used as an alternative for refracting telescopes during the 17th century because they suffer less chromatic aberrations than a refracting telescope does. <span>
</span></span>
Answer:
heat energy is used in boiling water and to make steam at power stations
Explanation:
Explanation:
for v vs t graph for t=9 to 11,v=15kmph
similarly v2=0,v3=60kmph&v4= -40kmph
Answer:20 minutes
Explanation:
06:58am - 06:38am =20 minutes
Given Information:
Length of wire = 132 cm = 1.32 m
Magnetic field = B = 1 T
Current = 2.2 A
Required Information:
(a) Torque = τ = ?
(b) Number of turns = N = ?
Answer:
(a) Torque = 0.305 N.m
(b) Number of turns = 1
Explanation:
(a) The current carrying circular loop of wire will experience a torque given by
τ = NIABsin(θ) eq. 1
Where N is the number of turns, I is the current in circular loop, A is the area of circular loop, B is the magnetic field and θ is angle between B and circular loop.
We know that area of circular loop is given by
A = πr²
where radius can be written as
r = L/2πN
So the area becomes
A = π(L/2πN)²
A = πL²/4π²N²
A = L²/4πN²
Substitute A into eq. 1
τ = NI(L²/4πN²)Bsin(θ)
τ = IL²Bsin(θ)/4πN
The maximum toque occurs when θ is 90°
τ = IL²Bsin(90)/4πN
τ = IL²B/4πN
torque will be maximum for N = 1
τ = (2.2*1.32²*1)/4π*1
τ = 0.305 N.m
(b) The required number of turns for maximum torque is
N = IL²B/4πτ
N = 2.2*1.32²*1)/4π*0.305
N = 1 turn
