Answer:
<h2>line B</h2>
Explanation:
According to ohm's law V = IR where;
V i sthe supply voltage (in volts)
I = supply current (in amperes)
R = resistance (in ohms)
In order to calculate the line that is equal to 2ohms, we need to calculate the slope of each line using the formula.
For line B, R = ΔV/ΔI
R = V₂-V₁/I₂-I₁
R = 14.0-4.0/7.0-2.0
R = 10.0/5.0
R = 2.0ohms
Since the slope of line B is equal to 2 ohms, this shows that the line B is the one that represents the 2ohms resistor.
Answer:
Sound vibrations travel in a wave pattern, and we call these vibrations sound waves. Sound waves move by vibrating objects and these objects vibrate other surrounding objects, carrying the sound along. ... Sound can move through the air, water, or solids, as long as there are particles to bounce off of.
Explanation:
Answer:
q_poly = 14.55 KJ/kg
Explanation:
Given:
Initial State:
P_i = 550 KPa
T_i = 400 K
Final State:
T_f = 350 K
Constants:
R = 0.189 KJ/kgK
k = 1.289 = c_p / c_v
n = 1.2 (poly-tropic index)
Find:
Determine the heat transfer per kg in the process.
Solution:
-The heat transfer per kg of poly-tropic process is given by the expression:
q_poly = w_poly*(k - n)/(k-1)
- Evaluate w_poly:
w_poly = R*(T_f - T_i)/(1-n)
w_poly = 0.189*(350 - 400)/(1-1.2)
w_poly = 47.25 KJ/kg
-Hence,
q_poly = 47.25*(1.289 - 1.2)/(1.289-1)
q_poly = 14.55 KJ/kg
From the word compound, the compound machine is already a combination of two or more types of simple machine. Thus, the answer is letter C. Because of its complexity, it is able to perform several other functions than a simple one.
