I need answers please i will give you 20
2 answers:
You might be interested in
Answer:
c. 70 Ω
Explanation:
The R and R resistors are in parallel. The 2R and 2R resistors are in parallel. The 4R and 4R resistors are in parallel. Each parallel combination is in series with each other. Therefore, the equivalent resistance is:
Req = 1/(1/R + 1/R) + 1/(1/2R + 1/2R) + 1/(1/4R + 1/4R)
Req = R/2 + 2R/2 + 4R/2
Req = 3.5R
Req = 70Ω
Answer:
(a) 1058.4 J
(b) -10584 J
Explanation:
Parameters given:
Mass of astronaut, m = 72 kg
Distance moved by astronaut, d = 15 m
(a) WORK DONE BY FORCE FROM THE HELICOPTER
Work done is given as the product of Force applied to a body and the distance moved by the body:
W = F * d
The force from the helicopter is given as:
F = m * a
where a = acceleration of the astronaut due to the helicopter
Therefore, the work done is given as:
W = m * a * d
W = 72 * g/10 * 15
W =
W = 1058.4 J
(b) WORK DONE BY FORCE OF GRAVITY
W = F * d
The force of gravity is given as:
F = -m * g
where g = acceleration due to gravity
The negative sign is due to the fact that the astronaut moves in an opposite direction (upwards) to the force of gravity (Gravity acts downwards)
Therefore, the work done is given as:
W = -m * g * d
W = -72 * 9.8 * 15
W = -10584 J
