Answer:
V1=5<u>ft3</u>
<u>V2=2ft3</u>
n=1.377
Explanation:
PART A:
the volume of each state is obtained by multiplying the mass by the specific volume in each state
V=volume
v=especific volume
m=mass
V=mv
state 1
V1=m.v1
V1=4lb*1.25ft3/lb=5<u>ft3</u>
state 2
V2=m.v2
V2=4lb*0.5ft3/lb= <u> 2ft3</u>
PART B:
since the PV ^ n is constant we can equal the equations of state 1 and state 2
P1V1^n=P2V2^n
P1/P2=(V2/V1)^n
ln(P1/P2)=n . ln (V2/V1)
n=ln(P1/P2)/ ln (V2/V1)
n=ln(15/53)/ ln (2/5)
n=1.377
Answer: The exit temperature of the gas in deg C is .
Explanation:
The given data is as follows.
= 1000 J/kg K, R = 500 J/kg K = 0.5 kJ/kg K (as 1 kJ = 1000 J)
= 100 kPa,
We know that for an ideal gas the mass flow rate will be calculated as follows.
or, m =
=
= 10 kg/s
Now, according to the steady flow energy equation:
= 5 K
= 5 K + 300 K
= 305 K
= (305 K - 273 K)
=
Therefore, we can conclude that the exit temperature of the gas in deg C is .
Answer:
0.31
126.23 kg/s
Explanation:
Given:-
- Fluid: Water
- Turbine: P3 = 8MPa , P4 = 10 KPa , nt = 85%
- Pump: Isentropic
- Net cycle-work output, Wnet = 100 MW
Find:-
- The thermal efficiency of the cycle
- The mass flow rate of steam
Solution:-
- The best way to deal with questions related to power cycles is to determine the process and write down the requisite properties of the fluid at each state.
First process: Isentropic compression by pump
P1 = P4 = 10 KPa ( condenser and pump inlet is usually equal )
h1 = h-P1 = 191.81 KJ/kg ( saturated liquid assumption )
s1 = s-P1 = 0.6492 KJ/kg.K
v1 = v-P1 = 0.001010 m^3 / kg
P2 = P3 = 8 MPa( Boiler pressure - Turbine inlet )
s2 = s1 = 0.6492 KJ/kg.K .... ( compressed liquid )
- To determine the ( h2 ) at state point 2 : Pump exit. We need to determine the wok-done by pump on the water ( Wp ). So from work-done principle we have:
- From the following relation we can determine ( h2 ) as follows:
h2 = h1 + wp
h2 = 191.81 + 8.0699
h2 = 199.88 KJ/kg
Second Process: Boiler supplies heat to the fluid and vaporize
- We have already evaluated the inlet fluid properties to the boiler ( pump exit property ).
- To determine the exit property of the fluid when the fluid is vaporized to steam in boiler ( super-heated phase ).
P3 = 8 MPa
T3 = ? ( assume fluid exist in the saturated vapor phase )
h3 = hg-P3 = 2758.7 KJ/kg
s3 = sg-P3 = 5.7450 KJ/kg.K
- The amount of heat supplied by the boiler per kg of fluid to the water stream. ( qs ) is determined using the state points 2 and 3 as follows:
Third Process: The expansion ( actual case ). Turbine isentropic efficiency ( nt ).
- The saturated vapor steam is expanded by the turbine to the condenser pressure. The turbine inlet pressure conditions are similar to the boiler conditions.
- Under the isentropic conditions the steam exits the turbine at the following conditions:
P4 = 10 KPa
s4 = s3 = 5.7450 KJ/kg.K ... ( liquid - vapor mixture phase )
- Compute the quality of the mixture at condenser inlet by the following relation:
- Determine the isentropic ( h4s ) at this state as follows:
- Since, we know that the turbine is not 100% isentropic. We will use the working efficiency and determine the actual ( h4 ) at the condenser inlet state:
- We can now compute the work-produced ( wt ) due to the expansion of steam in turbine.
- The net power out-put from the plant is derived from the net work produced by the compression and expansion process in pump and turbine, respectively.
Answer: The mass flow rate of the steam would be 126.23 kg/s
- The thermal efficiency of the cycle ( nth ) is defined as the ratio of net work produced by the cycle ( Wnet ) and the heat supplied by the boiler to the water ( Qs ):
Answer: The thermal efficiency of the cycle is 0.31
