Hi! Whoever can answer this question the best I will give the brainliest answer!!

1 answer:

6 0

A battery is a device that stores chemical energy and converts it to electrical energy. Two terminals made of different chemicals (typically metals), the anode and the cathode; and the electrolyte, which separates these terminals.
Hope I get it and hope this helps

You might be interested in

A galvanic cell is formed when two metals are immersed in solu- tions differing in concentration 1 when two different metals are

Citrus2011 [14]

A galvanic cell is formed when two metals are immersed in solu- tions differing in concentration 1 when two different metals are immersed.

<h3>What is galvanic cell?</h3>

The galvanic cell utilizes the ability to split the flow of electrons in the process of oxidization and reduction, compelling a half-reaction and connecting each with a wire so that a way can be formed for the flow of electrons via such wire.

A galvanic cell is an electrochemical cell that transforms the chemical energy of a spontaneous redox response into electrical energy. It has an electrical possibility equal to 1.1 V. In galvanic cells, oxidation occurs at the anode and it is a negative plate. Lessening occurs at the cathode and it is a positive plate.

A galvanic cell is an electrochemical cell that converts the free liveliness of a chemical method into electrical energy. A photogalvanic cell generates species photochemically which react resulting in an electrical current via an external circuit.

To learn more about galvanic cell, refer to:

brainly.com/question/13031093

#SPJ4

8 0

1 year ago

A 30.0-kg girl in a swing is pushed to one side and held at rest by a horizontal force \vec{F} F ⃗ so that the swing ropes

Virty [35]

Answer:

169.74 N

Explanation:

Given,

Mass of the girl = 30 Kg

angle of the rope with vertical, θ = 30°

equating the vertical component of the tension

vertical component of the tension is equal to the weight of the girl.

T cos θ = m g

T cos 30° = 30 x 9.8

T = 339.48 N

Tension on the two ropes is equal to 339.48 N

Tension in each of the rope = T/2

= 339.48/2 = 169.74 N

Hence, the tension in each of the rope is equal to 169.74 N

7 0

3 years ago

What was Neil Bohr's theory based on?

olganol [36]

b is the answer i hope this helped...

7 0

2 years ago

Read 2 more answers

Illustrates an Atwood's machine. Let the masses of blocks A and B be 7.00 kg and 3.00 kg , respectively, the moment of inertia o

Harman [31]

Answer:

A) 1.55

B) 1.55

C) 12.92

D) 34.08

E) 57.82

Explanation:

The free body diagram attached, R is the radius of the wheel

Block B is lighter than block A so block A will move upward while A downward with the same acceleration. Since no snipping will occur, the wheel rotates in clockwise direction.

At the centre of the whee, torque due to B is given by

${\tau _2} = - {T_{\rm{B}}}R$

Similarly, torque due to A is given by

${\tau _1} = {T_{\rm{A}}}R$

The sum of torque at the pivot is given by

$\tau = {\tau _1} + {\tau _2}$

Replacing ${\tau _1}$ and ${\tau _2}$ by ${T_{\rm{A}}}R$ and $- {T_{\rm{B}}}R$ respectively yields

$\begin{array}{c}\\\tau = {T_{\rm{A}}}R - {T_{\rm{B}}}R\\\\ = \left( {{T_{\rm{A}}} - {T_{\rm{B}}}} \right)R\\\end{array}$

Substituting $I\alpha$ for $\tau$ in the equation $\tau = \left( {{T_{\rm{A}}} - {T_{\rm{B}}}} \right)R$

$I\alpha=\left( {{T_{\rm{A}}} - {T_{\rm{B}}}} \right)R$

$\frac{I\alpha}{R} =\left {{T_{\rm{A}}} - {T_{\rm{B}}}} \right$

The angular acceleration of the wheel is given by $\alpha = \frac{a}{R}$

where a is the linear acceleration

Substituting $\frac{a}{R}$ for $\alpha$ into equation

$\frac{I\alpha}{R} =\left {{T_{\rm{A}}} - {T_{\rm{B}}}} \right$ we obtain

$\frac{Ia}{R^2} =\left {{T_{\rm{A}}} - {T_{\rm{B}}}} \right$

Net force on block A is

${F_{\rm{A}}} = {m_{\rm{A}}}g - {T_{\rm{A}}}$

Net force on block B is

${F_{\rm{B}}} = {T_{\rm{B}}} - {m_{\rm{B}}}g$

Where g is acceleration due to gravity

Substituting ${m_{\rm{B}}}a$ and ${m_{\rm{A}}}a$ for ${F_{\rm{B}}}$ and ${F_{\rm{A}}}$ respectively into equation $\frac{Ia}{R^2} =\left {{T_{\rm{A}}} - {T_{\rm{B}}}} \right$ and making a the subject we obtain

$\begin{array}{c}\\{m_{\rm{A}}}g - {m_{\rm{A}}}a - \left( {{m_{\rm{B}}}g + {m_{\rm{B}}}a} \right) = \frac{{Ia}}{{{R^2}}}\\\\\left( {{m_{\rm{A}}} - {m_{\rm{B}}}} \right)g - \left( {{m_{\rm{A}}} + {m_{\rm{B}}}} \right)a = \frac{{Ia}}{{{R^2}}}\\\\\left( {{m_{\rm{A}}} + {m_{\rm{B}}} + \frac{I}{{{R^2}}}} \right)a = \left( {{m_{\rm{A}}} - {m_{\rm{B}}}} \right)g\\\\a = \frac{{\left( {{m_{\rm{A}}} - {m_{\rm{B}}}} \right)g}}{{\left( {{m_{\rm{A}}} + {m_{\rm{B}}} + \frac{I}{{{R^2}}}} \right)}}\\\end{array}$

Since ${m_{\rm{B}}}$ = 3kg and ${m_{\rm{B}}}$ = 7kg

g=9.81 and R=0.12m, I=0.22 ${\rm{ kg}} \cdot {{\rm{m}}^2}$

Substituting these we obtain

$a = \frac{{\left( {{m_{\rm{A}}} - {m_{\rm{B}}}} \right)g}}{{\left( {{m_{\rm{A}}} + {m_{\rm{B}}} + \frac{I}{{{R^2}}}} \right)}}$

$\begin{array}{c}\\a = \frac{{\left( {7{\rm{ kg}} - 3{\rm{ kg}}} \right)\left( {9.81{\rm{ m/}}{{\rm{s}}^2}} \right)}}{{\left( {7{\rm{ kg}} + 3{\rm{ kg}} + \frac{{0.22{\rm{ kg/}}{{\rm{m}}^2}}}{{{{\left( {0.120{\rm{ m}}} \right)}^2}}}} \right)}}\\\\ = 1.55235{\rm{ m/}}{{\rm{s}}^2}\\\end{array}$

Therefore, the linear acceleration of block A is 1.55 ${\rm{ m/}}{{\rm{s}}^2}$

(B)

For block B

${a_{\rm{B}}} = {a_{\rm{A}}}$

Therefore, the acceleration of both blocks A and B are same

1.55 ${\rm{ m/}}{{\rm{s}}^2}$

(C)

The angular acceleration is $\alpha = \frac{a}{R}$

$\begin{array}{c}\\\alpha = \frac{{1.55{\rm{ m/}}{{\rm{s}}^2}}}{{0.120{\rm{ m}}}}\\\\ = 12.92{\rm{ rad/}}{{\rm{s}}^2}\\\end{array}$

(D)

Tension on left side of cord is calculated using

$\begin{array}{c}\\{T_{\rm{B}}} = {m_{\rm{B}}}g + {m_{\rm{B}}}a\\\\ = {m_{\rm{B}}}\left( {g + a} \right)\\\end{array}$

$\begin{array}{c}\\{T_{\rm{B}}} = \left( {3{\rm{ kg}}} \right)\left( {9.81{\rm{ m/}}{{\rm{s}}^2} + 1.55{\rm{ m/}}{{\rm{s}}^2}} \right)\\\\ = 34.08{\rm{ N}}\\\end{array}$

(E)

Tension on right side of cord is calculated using

$\begin{array}{c}\\{T_{\rm{A}}} = {m_{\rm{A}}}g - {m_{\rm{A}}}a\\\\ = {m_{\rm{A}}}\left( {g - a} \right)\\\end{array}$

$\begin{array}{c}\\{T_{\rm{A}}} = \left( {7{\rm{ kg}}} \right)\left( {9.81{\rm{ m/}}{{\rm{s}}^2} – 1.55{\rm{ m/}}{{\rm{s}}^2}} \right)\\\\ = 57.82{\rm{ N}}\\\end{array}$

6 0

2 years ago

A box of mass 60 kg is at rest on a horizontal floor that has a static coefficient of friction of 0.6 and a kinetic coefficient

gavmur [86]

Answer:

a) The minimum force required to start moving the box is 352.86 N

b) i) The friction force for the box in motion is 147.025 N

ii) The acceleration of box is 4.21625 m/s²

Explanation:

The parameters of the box at rest and the floor are;

The mass of the box = 60 kg

The static coefficient friction of the floor = 0.6

The kinetic coefficient friction of the floor = 0.25

Frictional force = Normal force × Friction coefficient

For an horizontal floor and the box laying on the floor, we have;

The normal force = The weight of the box = Mass of the box × Acceleration due to gravity, g

The acceleration due to gravity, g = 9.81 m/s²

The weight of the box = 60 × 9.81 = 588.6 N

a) The static coefficient gives the frictional force observed by the box and which must be surpassed to bring about motion

Therefore;

The minimum force required to start moving the box = The static frictional force = Weight of the box × The static coefficient of friction

The minimum force required to start moving the box = 588.1 × 0.6 = 352.86 N

The minimum force required to start moving the box = 352.86 N

b) i) When an horizontal force of 400 N is applied, the applied force is larger than the static friction force, and the box will be in motion with the kinetic coefficient of friction being the source of friction

The friction force for the box in motion = 588.1 × 0.25 = 147.025 N

ii) The force, F with the box is in motion, is given as follows;

F = Mass of box × Acceleration of box, a = Applied force - Kinematic friction force

F = 60 × a = 400 - 147.025 = 252.975 N

60 × a = 252.975 N

a = 252.975 N/(60 kg) = 4.21625 m/s²

Acceleration of box, a = 4.21625 m/s².

6 0
