Don't break or crush mercury-containing lamps because mercury powder may be released.

If the driver gear has 5 teeth and the driven gear has 10 teeth,what is the gear ratio?

shepuryov [24]

The on that has ten teeth

6 0

3 years ago

Hot carbon dioxide exhaust gas at 1 atm is being cooled by flat plates. The gas at 220 °C flows in parallel over the upper and l

sergeinik [125]

The local convection heat transfer coefficient at 1 m from the leading edge is $0.44 \frac{W}{m^{2} \times K}$ , the average convection heat transfer coefficient over the entire plate is $0.293 \frac{W}{m^{2} \times K}$ and the total heat flux transfer to the plate is $61.6 KJ$ .

Explanation:

It is case of heat and mass transfer in which due to temperature difference between gas and surface. Further temperature boundary layer will developed on flat plate in longitudinal direction.

Hot carbon dioxide exhaust gas

physical properties

$r= 1.05 \frac{kg}{m^{3}}$

$c_p = 1.02 \frac{kJ}{Kg \times K}$

$m= 231 \times 10^{7} \frac{N \times s }{m^2}$

υ = $21.8 \times 10^{6} \frac{m^2}{s}$

$k = 32.5 \times 10^{3} \frac{W}{m \times K}$

$\alpha = 30.1 \times 10^{6} \frac{m^{2}}{s}$

$Pr = 0.725$

Apart from these other data arr given below,

$v= 3 \frac{m}{s} \\ p= 1 atm \\ L_c = 1.5m \\T_g= 220 C \\ T_s = 80 C$

To find the local convection heat transfer coefficient at 1 m from the leading edge, we use correlation used for laminar flow over flat plate,

$Nu = \frac{ h \times L }{k} = 0.332 \times (Re^{\frac{1}{2} }) \times (Pr^{\frac{1}{3} })$

where h= Average heat transfer coefficient

L= Length of a plate

k= Thermal Conductivity of carbon dioxide

Re = Reynold's Number

Pr = Prandtle Number

(a) Convection heat transfer coefficient at 1 m from the leading edge

is referred as local convection heat transfer coefficient.

To find convection heat transfer coefficient at 1 m from leading edge,

$Nu = \frac{ h_local \times L }{k} = 0.332 \times (Re^{\frac{1}{2} }) \times (Pr^{\frac{1}{3} })$

Here, first we have to find Re and Pr,

$Re = \frac{r \times v \times L}{m}$

$Re = \frac{1.0594 \times 3 \times 1}{231 \times 10^{7}}$

$Re = 20.63 \times 10^{-10}$

Pr number is take from physical property data and Pr is 0.725.

Putting value of Re and Pr in main equation,

we get

$Nu = \frac{ h_local \times 1 }{32.5 \times 10^{3}} = 0.332 \times ( (20.63 \times 10^{-10})^{\frac{1}{2} }) \times (0.725^{\frac{1}{3} })$

$h_local = 32.5 \times 10^{3} \times 0.332 \times ( (20.63 \times 10^{-10})^{\frac{1}{2} }) \times (0.725^{\frac{1}{3} })$

$h_local = 0.44 \frac{W}{m^{2} \times K}$

(b) To find average convection heat transfer coefficient,

it can be find out as case (a), only difference is that instead of L=1 m, L=1.5 m would come,

Therefore,

$Nu = \frac{ h \times 1.5 }{32.5 \times 10^{3}} = 0.332 \times ( (20.63 \times 10^{-10})^{\frac{1}{2} }) \times (0.725^{\frac{1}{3} })$

Finally,

$h = \frac{0.44}{1.5}$

$h = 0.293 \frac{W}{m^{2} \times K}$

(C) Total heat flux transfer to the plate is found out by,

$Q = h \times (T_g - T_s)$

$Q = 0.293 \times (220-80) \\ Q= 0.293 \times 140 \\ Q= 61.6 KJ$

8 0

3 years ago

For a bronze alloy, the stress at which plastic deformation begins is 266 MPa and the modulus of elasticity is105 GPa.

pentagon [3]

Answer:

88750 N

Explanation:

given data:

plastic deformation σy=266 MPa=266*10^6 N/m^2

cross-sectional area Ao=333 mm^2=333*10^-6 m^2

solution:

To determine the maximum load that can be applied without

plastic deformation (Fy).

Fy=σy*Ao

=88750 N

7 0

3 years ago

What are Tresca and Von Mises yield criteria?

elena-s [515]

Answer

For isotropic material plastic yielding depends upon magnitude of the principle stress not on the direction.

Tresca and Von Mises yield criteria are the yield model which is widely used.

The Tresca yield criterion stated that yielding will occur in a material only when the greatest maximum shear stress reaches a critical value.

max{|σ₁ - σ₂|,|σ₂ - σ₃|,|σ₃ - σ₁|} = σ_f

under plane stress condition

|σ₁ - σ₂| = σ_f

The Von mises yielding criteria stated that the yielding will occur when elastic energy of distortion reaches critical value.

σ₁² - σ₁ σ₂ + σ₂² = σ²_f

5 0

3 years ago

When lining up the song on the tempo grid it is important to allow

Reika [66]

Tempo decides the speed at which the music is played.

<u>Explanation:</u>

The Tempo of a bit of music decides the speed at which it is played, and is estimated in beats per minute (BPM). The 'beat' is dictated when mark of the piece, so 100 BPM in 4/4 compares to 100 quarter notes in a single moment.

A quick tempo, prestissimo, has somewhere in the range of 200 and 208 beats for each moment, presto has 168 to 200 beats for every moment, allegro has somewhere in the range of 120 and 168 beats for every moment, moderato has 108 to 120 beats for every moment, moderately slow and even has 76 to 108, adagio has 66 to 76, larghetto has 60 to 66, and largo, the slowest rhythm, has 40 to 60.
