An electric heater is operated by applying a potential difference of 78.0 V across a nichrome wire of total resistance 7.00 Ω. a

) Find the current in the wire. Answer in units of A.
b) Find the power rating of the heater. Answer in units of W.

1 answer:

aleksley [76]3 years ago

8 0

PART A)

Here we know that

potential difference across the wire is

$V = 78 volts$

resistance of wire is

$R = 7 ohm$

now by ohm's law

$V = iR$

$78 = i(7 ohm)$

$i = 11.14 A$

Part b)

Power rating is defined as rate of electrical energy

it is defined as

$P = iV$

now we have

$P = 11.14 ( 78)$

$P = 869.1 Watt$

You might be interested in

Problem: The frequency of an FM radio station is 89.3 MHz. Calculate its period. Part B: From the Library, select the general eq

vekshin1

Answer:

Time period, $T=1.11\times 10^{-8}\ s$

Explanation:

We have,

The frequency of an FM radio station is 89.3 MHz.

It is required to find the period of the wave.

The reciprocal of frequency is called time period of a wave. It can be given by :

$T=\dfrac{1}{f}\\\\T=\dfrac{1}{89.3\times 10^{6}\ Hz}\\\\T=1.11\times 10^{-8}\ s$

So, the period of the wave is $1.11\times 10^{-8}\ s$ .

5 0

3 years ago

Leslie incorrectly balances an equation as 2C4H10 + 12O2 → 8CO2 + 10H2O.

tatiyna

Answer:

13 behind o2

Explanation:

answer is in photo above

4 0

3 years ago

I would love to stretch a wire from our house to the Shop so I can 'call' my husband in for meals. The wire could be tightened t

dezoksy [38]

Note: I'm not sure what do you mean by "weight 0.05 kg/L". I assume it means the mass per unit of length, so it should be "0.05 kg/m".

Solution:
The fundamental frequency in a standing wave is given by
$f= \frac{1}{2L} \sqrt{ \frac{T}{m/L} }$
where L is the length of the string, T the tension and m its mass. If we plug the data of the problem into the equation, we find
$f= \frac{1}{2 \cdot 24 m} \sqrt{ \frac{240 N}{0.05 kg/m} }=1.44 Hz$

The wavelength of the standing wave is instead twice the length of the string:
$\lambda=2 L= 2 \cdot 24 m=48 m$

So the speed of the wave is
$v=\lambda f = (48 m)(1.44 Hz)=69.1 m/s$

And the time the pulse takes to reach the shop is the distance covered divided by the speed:
$t= \frac{L}{v}= \frac{24 m}{69.1 m/s}=0.35 s$

7 0

4 years ago

Suppose Joe, who can type 40 words per minute, takes 2.5 hours to type his report. To speed things up, his friend Mark offers to

Vika [28.1K]

Explanation:

When Joe works alone, the total number of words he typed can be given by:

Total words = (40 words per minute) x (60 minutes per hour) x (2.5 hours)

Total words = 6000 words

Now, when Joe and Mark work together, let 'y' be the number of hours for which they both work simultaneously:

Total words = Words Typed by Joe + Words Typed by Mark

6000 = {(40 words per minute) x (60 minutes per hours) x (y hours)} + {(20 words per minute) x (60 minutes per hours) x (y hours)}

6000 = 2400y + 1200y = 3600y

y = 1.67 hours = 1 hour and 40 minutes

Thus, working together simultaneously, Joe and Mark will take 1 hour and 40 minutes to complete the report.

5 0

3 years ago

A hollow cylinder that is rolling without slipping is given a velocity of 5.0 m/s and rolls up an incline to a vertical height o

inysia [295]

Answer:

The hollow cylinder rolled up the inclined plane by 1.91 m

Explanation:

From the principle of conservation of mechanical energy, total kinetic energy = total potential energy

$M.E_T = \frac{1}{2}mv^2 + \frac{1}{2} I \omega^2 + mgh$

The total energy at the bottom of the inclined plane = total energy at the top of the inclined plane.

$\frac{1}{2}mv_i^2 + \frac{1}{2} I \omega_i^2 + mg(0) = \frac{1}{2}mv_f^2 + \frac{1}{2} I \omega_f^2 + mgh$

moment of inertia, I, of a hollow cylinder = ¹/₂mr²

substitute for I in the equation above;

$\frac{1}{2}mv_i^2 + \frac{1}{2} (\frac{1}{2}mr^2 \omega_i^2) = \frac{1}{2}mv_f^2 + \frac{1}{2} (\frac{1}{2}mr^2 \omega_f^2) + mgh\\\\ but \ v = r \omega\\\\\frac{1}{2}mv_i^2 + \frac{1}{2} (\frac{1}{2}m v_i^2 ) = \frac{1}{2}mv_f^2 + \frac{1}{2} (\frac{1}{2}m v_f^2) + mgh\\\\\frac{1}{2}mv_i^2 +\frac{1}{4}mv_i^2 = \frac{1}{2}mv_f^2 +\frac{1}{4}mv_f^2 +mgh\\\\\frac{3}{4}mv_i^2 = \frac{3}{4}mv_f^2 +mgh\\\\mgh = \frac{3}{4}mv_i^2 - \frac{3}{4}mv_f^2\\\\gh = \frac{3}{4}v_i^2 - \frac{3}{4}v_f^2\\\\$

$h = \frac{3}{4g}(v_1^2 -v_f^2)$

given;

v₁ = 5.0 m/s

vf = 0

g = 9.8 m/s²

$h = \frac{3}{4g}(v_1^2 -v_f^2) =\frac{3}{4*9.8}(5^2 -0) = 1.91 \ m$

Therefore, the hollow cylinder rolled up the inclined plane by 1.91 m

5 0

3 years ago
