A quantity of gas has a volume of 0.20 cubic meter and an absolute temperature of 333 degrees kelvin. When the temperature of th

e gas is raised to 533 degrees kelvin, what is the new volume of the gas? (Assume that there's no change in pressure.)

1 answer:

Elena L [17]3 years ago

7 0

P1v1/t1 = p2v2/t2

p1=p2, v1=.2, t1=333, t2=533
we can find v2 from this

be aware, temperature must be in Kelvin.

You might be interested in

A 438kg car is accelerating east at 2.55m/s^2. What is the total force acting east on the car

lisabon 2012 [21]

Answer:

<h2>1116.9 N</h2>

Explanation:

The force acting on an object given it's mass and acceleration can be found by using the formula

force = mass × acceleration

From the question we have

force = 438 × 2.55

We have the final answer as

<h3>1116.9 N</h3>

Hope this helps you

5 0

3 years ago

Does gravity have an effect on the potential difference of a battery?

Sonja [21]

Answer: The correct answer is "No".

Explanation:

Gravity: It is the force which causes object to fall on the earth. It is the force which attracts bodies towards each other.

Potential difference: It is defined as the potential acting between the two points. The work done in moving the unit positive charge from one location to the another location.

The potential difference in battery is caused by the electrodes. There are two terminals in battery: Negative terminal which is at lower potential and Positive terminal which is at higher potential. It forces the electrons to flow in the circuit which constitutes the current.

The gravity and the potential difference have no relation between them.

Therefore, gravity have no effect on the potential difference of a battery.

5 0

3 years ago

to 10 Hz. Superimposed on this signal is 60-Hz noise with an amplitude of 0.1 V. It is desired to attenuate the 60-Hz signal to

givi [52]

Answer:

$G \sqrt{1 +(\frac{f}{f_c})^{2n}} = 1$

If we square both sides we got:

$G^2 (1+\frac{f}{f_c})^{2n}= 1$

We divide both sides by $G^2$ and we got:

$(1+\frac{f}{f_c})^{2n} = \frac{1}{G^2}$

Now we can apply log on both sides and we got:

$2n ln(1+\frac{f}{f_c}) = ln (\frac{1}{G^2})$

And solving for n we got:

$n = \frac{ ln (\frac{1}{G^2})}{2ln(1+\frac{f}{f_c})}$

And replacing we got:

$n = \frac{ln (\frac{1}{0.1^2})}{2ln(1+\frac{60}{10})}$

$n = \frac{4.60517}{3.8918}=1.18$

And since n needs to be an integer the correct answer would be n=2 for the filter order.

Explanation:

For this case we can use the formula for the Butterworth filter gain given by:

[tec] G = \frac{1}{\sqrt{1 +(\frac{f}{f_c})^{2n}}}[/tex]

Where:

G represent the transfer function and we want that G =0.1 since the desired signal is less than 10% of it's value

$f_c = 10 Hz$ represent the corner frequency

$f= 60 Hz$ represent the original frequency

n represent the filter order and that's the variable that we need to find

$G \sqrt{1 +(\frac{f}{f_c})^{2n}} = 1$

If we square both sides we got:

$G^2 (1+\frac{f}{f_c})^{2n}= 1$

We divide both sides by $G^2$ and we got:

$(1+\frac{f}{f_c})^{2n} = \frac{1}{G^2}$

Now we can apply log on both sides and we got:

$2n ln(1+\frac{f}{f_c}) = ln (\frac{1}{G^2})$

And solving for n we got:

$n = \frac{ ln (\frac{1}{G^2})}{2ln(1+\frac{f}{f_c})}$

And replacing we got:

$n = \frac{ln (\frac{1}{0.1^2})}{2ln(1+\frac{60}{10})}$

$n = \frac{4.60517}{3.8918}=1.18$

And since n needs to be an integer the correct answer would be n=2 for the filter order.

7 0

3 years ago

Suppose that you're facing a straight current-carrying conductor, and the current is flowing toward you. The lines of magnetic f

alekssr [168]

Answer:c

Explanation:

When the direction of current is towards the observer then the magnetic field around it will be in the form of concentric circles and its direction will be anti-clockwise when viewed from the observer side.

Whenever current is flowing in a current-carrying conductor then the magnetic field is associated with it and direction of the magnetic field is given by right-hand thumb rule according to which if thumb represents the direction of current then wrapping of fingers will give the direction of the magnetic field

8 0

3 years ago

A spring has a spring constant of 90N/m.How much potential energy does it store when stretched by 2 cm?

il63 [147K]

Answer:

The potential energy stored in the spring is 0.018 J.

Explanation:

Given;

spring constant, k = 90 N/m

extension of the spring, x = 2 cm = 0.02 m

The potential energy stored in the spring is calculated as;

U = ¹/₂kx²

where;

U is the potential energy stored in the spring

Substitute the given values in the equation above;

U = ¹/₂ x 90 N/m x (0.02 m)²

U = 0.018 J

Therefore, the potential energy stored in the spring is 0.018 J.

5 0
