PLEASE PLEASE PLEASE HELP!!!! WILL MARK BRAINILIEST!!!!!!!!!!!

Physics

1 answer:

xxTIMURxx [149]4 years ago

6 0

Answer:

The purpose of our major is to deepen knowledge and understanding of one of the most powerful forces operating on people, communities and corporations today, namely government and politics in the USA and around the world. This knowledge and understanding is valuable for all citizens.

You might be interested in

The inner cylinder of a long, cylindrical capacitor has radius r and linear charge density +λ. It is surrounded by a coaxial cyl

Ulleksa [173]

Hi there!

We can begin by using the equation for energy density.

$U = \frac{1}{2}\epsilon_0 E^2$

U = Energy (J)

ε₀ = permittivity of free space

E = electric field (V/m)

First, derive the equation for the electric field using Gauss's Law:
$\Phi _E = \oint E \cdot dA = \frac{Q_{encl}}{\epsilon_0}$

Creating a Gaussian surface being the lateral surface area of a cylinder:
$A = 2\pi rL\\\\E \cdot 2\pi rL = \frac{Q_{encl}}{\epsilon_0}\\\\Q = \lambda L\\\\E \cdot 2\pi rL = \frac{\lambda L}{\epsilon_0}\\\\E = \frac{\lambda }{2\pi r \epsilon_0}$

Now, we can calculate the energy density using the equation:
$U = \frac{1}{2} \epsilon_0 E^2$

Plug in the expression for the electric field and solve.

$U = \frac{1}{2}\epsilon_0 (\frac{\lambda}{2\pi r \epsilon_0})^2\\\\U = \frac{\lambda^2}{8\pi^2r^2\epsilon_0}$

Now, we can integrate over the volume with respect to the radius.

Recall:
$V = \pi r^2L \\\\dV = 2\pi rLdr$

Now, we can take the integral of the above expression. Let:
$r_i$ = inner cylinder radius

$r_o$ = outer cylindrical shell inner radius

Total energy-field energy:

$U = \int\limits^{r_o}_{r_i} {U_D} \, dV = \int\limits^{r_o}_{r_i} {2\pi rL *U_D} \, dr$

Plug in the equation for the electric field energy density and solve.

$U = \int\limits^{r_o}_{r_i} {2\pi rL *\frac{\lambda^2}{8\pi^2r^2\epsilon_0}} \, dr\\\\U = \int\limits^{r_o}_{r_i} { L *\frac{\lambda^2}{4\pi r\epsilon_0}} \, dr\\$

Bring constants in front and integrate. Recall the following integration rule:
$\int {\frac{1}{x}} \, dx = ln(x) + C$

Now, we can solve!

$U = \frac{\lambda^2 L}{4\pi \epsilon_0}\int\limits^{r_o}_{r_i} { \frac{1}{r}} \, dr\\\\\\U = \frac{\lambda^2 L}{4\pi \epsilon_0} ln(r)\left \| {{r_o} \atop {r_i}} \right. \\\\U = \frac{\lambda^2 L}{4\pi \epsilon_0} (ln(r_o) - ln(r_i))\\\\U = \frac{\lambda^2 L}{4\pi \epsilon_0} ln(\frac{r_o}{r_i})$

To find the total electric field energy per unit length, we can simply divide by the length, 'L'.

$\frac{U}{L} = \frac{\lambda^2 L}{4\pi \epsilon_0} ln(\frac{r_o}{r_i})\frac{1}{L} \\\\\frac{U}{L} = \boxed{\frac{\lambda^2 }{4\pi \epsilon_0} ln(\frac{r_o}{r_i})}$
