Answer: 567 N
Explanation:
If the weight of the person and the bike are supported equally by the two tires, this means that the force acting on each tire, is half of the total weight.
We know that the gauge pressure in one tire, by definition, is equal to the force on the tire, over the contact surface between each tire and the road, so we can write:
P= F/A = (mrider g + mbike g) / A = (Fgrider + 7.5 kg. 9.8 m/s2) / 703 mm2 (1)
As the pressure data is given in lb/in2, it is needed to convert to N/mm2, as follows:
65.5 lb/in2 = 0.455 N/mm2.
Replacing in (1), and solving for Fgrider, we have:
Fgrider = 567 N
Answer:
Explanation:
Recall weight density of water 62.5 lb/ft^3 and the height 6ft base 8ft
The width of the triangle
The hydrostatic force is the pressure times area of the submerged
![F=109.375[4x^2-\frac{1}{3}x^3]|4,8](https://tex.z-dn.net/?f=F%3D109.375%5B4x%5E2-%5Cfrac%7B1%7D%7B3%7Dx%5E3%5D%7C4%2C8)
Si aumentamos el radio de la trayectoria circular, necesitariamos menos fuerza para mantenerlo en el camino
