8_murik_8 [283]
3 years ago
8

A small solid conductor with radius a is supported by insulating, nonmagnetic disks on the axis of a thin-walled tube with inner

radius b. The inner andouter conductors carry equal currents i in oppositedirections.
Required:
a. Use Ampere's Law to find the magnetic field at any pointin the volume between the conductors.
b. Write the expression for the flux dΦB through anarrow strip of length l parallel to the axis , of width dr, at a distancer from the axis of the cableand lying in a plane containing the axis.
c. Integrate your expression from part B over the volumebetween the two conductors to find the total flux produced by acurrent i in the central conductor.
d. Use equation U=(1/2)LI2 to calculate the energy stored in the magnetic field for alength l of the cable.

Physics
1 answer:
Ugo [173]3 years ago
5 0

Answer:

Pls see attached file

Explanation:

You might be interested in
A car speeding down the highway honks its horn, which has a frequency 392 Hz, but a resting bystander hears the frequency 440 Hz
Natali [406]

Answer:

37.42 m/s

Explanation:

We know that apparent frequency, \bar f is given by

\bar f=f\frac {V}{V-V_s} where f is the given frequency in this case 392, V is the speed of sound in air which is given as 343 and V_s is the speed of car which is unknown, \bar f is given as 440 Hz

440=392\times \frac {343}{343-V_s}\\343-V_s=392\times \frac {343}{440}=305.5818182\\V_s=343-305.5818182=37.41818182\approx 37.42 m/s

8 0
3 years ago
List the planets that have MORE THAN 3 moons.
antiseptic1488 [7]

Answer:

jupiter they have 79 moons,saturn has 62,uranus has 27,neptune has 14,pluto has 5,

Explanation:

6 0
4 years ago
Options: A.) 10 N B.) 15 N C.) 25 N D.) 35N
Lady_Fox [76]

Given:

F_gravity = 10 N

F_tension = 25 N

Let's find the net centripetal force exterted on the ball.

Apply the formula:

\sum ^{}_{}F_{\text{net}}=F_1+F_2=F_{centripetal}

From the given figure, the force acting towards the circular path will be positive, while the force which points directly away from the center is negative.

Hence, the tensional force is positive while the gravitational force is negative.

Thus, we have:

F_{\text{net}}=F_{\text{centripetal}}=F_{tension}-F_{gravity}=25N-10N=15N

Therefore, the net centripetal force exterted on the ball is 15 N.

ANSWER:

15 N

7 0
1 year ago
Within the theory of G relativity what, exactly, is meant by " the speed of light WITHIN A VACUUM" ? & what does that have t
Ber [7]
The speed of light "within a vacuum" refers to the speed of electromagnetic radiation propagating in empty space, in the complete absence of matter.  This is an important distinction because light travels slower in material media and the theory of relativity is concerned with the speed only in vacuum.  In fact, the theory of relativity and the "speed of light" actually have nothing to do with light at all.  The theory deals primarily with the relation between space and time and weaves them into an overarching structure called spacetime.  So where does the "speed of light" fit into this?  It turns out that in order to talk about space and time as different components of the same thing (spacetime) they must have the same units.  That is, to get space (meters) and time (seconds) into similar units, there has to be a conversion factor.  This turns out to be a velocity.  Note that multiplying time by a velocity gives a unit conversion of
seconds \times  \frac{meters}{seconds} =meters
This is why we can talk about lightyears.  It's not a unit of time, but distance light travels in a year.  We are now free to define distance as a unit of time because we have a way to convert them.
As it turns out light is not special in that it gets to travel faster than anything else.  Firstly, other things travel that fast too (gravity and information to name two).  But NO events or information can travel faster than this.  Not because they are not allowed to beat light to the finish line---remember my claim that light has nothing to do with it.  It's because this speed (called "c") converts space and time.  A speed greater than c isn't unobtainable---it simply does not exist.  Period.  Just like I can't travel 10 meters without actually moving 10 meters, I cannot travel 10 meters without also "traveling" at least about 33 nanoseconds (about the time it takes light to get 10 meters)  There is simply no way to get there in less time, anymore than there is a way to walk 10 meters by only walking 5.
We don't see this in our daily life because it is not obvious that space and time are intertwined this way.  This is a result of our lives spent at such slow speeds relative to the things around us.
This is the fundamental part to the Special Theory of Relativity (what you called the "FIRST" part of the theory)  Here is where Einstein laid out the idea of spacetime and the idea that events (information) itself propagates at a fixed speed that, unlike light, does not slow down in any medium.  The idea that what is happening "now" for you is not the same thing as what is "now" for distant observers or observers that are moving relative to you.  It's also where he proposed of a conversion factor between space and time, which turned out to be the speed of light in vacuum.
3 0
4 years ago
A particle moves along the x axis so that its velocity at time t is given by v(t)=
vodomira [7]

Answer:

a = 0.7267 ,  acceleration is positive therefore the speed is increasing

Explanation:

The definition of acceleration is

         a = dv / dt

they give us the function of speed

         v = - (t-1) sin (t² / 2)

         a = - sin (t²/2) -  (t-1) cos (t²/2)  2t / 2

         a = - sin (t²/2) - t (t-1)  cos (t²/2)

the acceleration for t = 4 s

          a = - sin (4²/2) - 4 (4-1) cos (4²/2)

          a = -sin 8 - 12 cos 8

remember that the angles are in radians

          a = 0.7267

the problem does not indicate the units, but to be correct they must be m/s²

We see that the acceleration is positive therefore the speed is increasing

6 0
3 years ago
