Given Information:
Power = P = 100 Watts
Voltage = V = 220 Volts
Required Information:
a) Current = I = ?
b) Resistance = R = ?
Answer:
a) Current = I = 0.4545 A
b) Resistance = R = 484 Ω
Explanation:
According to the Ohm’s law, the power dissipated in the light bulb is given by
Where V is the voltage across the light bulb, I is the current flowing through the light bulb and P is the power dissipated in the light bulb.
Re-arranging the above equation for current I yields,
Therefore, 0.4545 A current is flowing through the light bulb.
According to the Ohm’s law, the voltage across the light bulb is given by
Where V is the voltage across the light bulb, I is the current flowing through the light bulb and R is the resistance of the light bulb.
Re-arranging the above equation for resistance R yields,
Therefore, the resistance of the bulb is 484 Ω
The amount of heat needed to increase the temperature of a substance by
is given by
where m is the mass of the substance, Cs is its specific heat capacity and is the increase of temperature.
If we re-arrange the formula, we get
And if we plug the data of the problem into the equation, we can find the specific heat capacity of the substance:
where m is the mass of the substance, Cs is its specific heat capacity and
If we re-arrange the formula, we get
And if we plug the data of the problem into the equation, we can find the specific heat capacity of the substance:
Answer:
a) 20 rad/s
b) 6 m/s
Explanation:
b) Force acting on the wheel is 200 N
mass of the wheel is 100 kg
From Newton's second law of motion, F = m × a
Where F is the net force acting on the body
m is mass of the body
a is the acceleration of the body
By substituting the values we get, a = 2 m/s²
As acceleration is constant, we can use the below formula for calculating the final velocity of the object
v = u + a × t
Where v is the final velocity
u is the initial velocity
a is the acceleration
t is the time taken
u = 0 (∵ it starts from rest)
By substituting the values we get
v = 0 + 2 × 3 = 6 m/s
∴ Speed of center of mass after 3 seconds = 6 m/s
a) As the wheel rotates about z-axis, radius of gyration will be the radius of wheel
∴ Radius of the wheel = 300 mm
Torque acting on the wheel about axis of rotation = 300 mm × 200 N =
60 N·m
Torque = (Moment of inertia) × (angular acceleration)
Assuming that the mass of spokes of the wheel to be negligible,
Moment of inertia of the wheel about axis of rotation = 100 × 300² × = 9 kg·m²
Then,
60 = 9 × (angular acceleration)
∴ angular acceleration ≈ 6·67 rad/s²
As angular acceleration of the wheel is constant, we can use the below formula for calculation of final angular speed
=
+ α × t
Where
is the final angular velocity
is the initial angular velocity
α is the angular acceleration
t is the time taken
is 0 (∵ initially it starts from rest)
By substituting the values we get
= 6·67 × 3 = 20 rad/s
∴ Angular velocity of the wheel after three seconds = 20 rad/s
