Answer:
Explanation:
a ) V( primary ) = 100 V
V( secondary ) = 10 V
No of turns ( secondary ) / No of turns ( primary ) = 10 / 100
= 1 / 10
b ) current in secondary
= volt ( secondary ) / resistance
= 10 /6 = 1.67 A
c )
Average power to secondary
= V ( secondary ) x current ( secondary )
= 10 x 10 / 6
= 16.67 W
d )
Power in primary = power in secondary = 16.67 W
e ) current drawn by ac line ( primary )
Volt ( primary ) x current ( primary ) = power in primary
= 16.67
current ( primary )
= 16.67 / 100
= 0.167 A
Answer:
Explanation:
We know that the magnetic Field of the Earth is 50\mu T, so the equation for
Hall effect voltage und magnetic field are defined as,
So,
<em>It is the process in which green plants make their food through a green pigment known as Chlorophyll by using sunlight, Carbon-dioxide and water</em>. <em>The result comes out with the formation of Oxygen as a byproduct. But in night they also respire like animals and photosynthesis does not occur. Photo means light and synthesis means manufacture.</em>
Answer:
The intensity of the sound in W/m² is 1 x 10⁻⁶ W/m².
Explanation:
Given;
intensity of the sound level, dB = 60 dB
The intensity of the sound in W/m² is calculated as;
![dB = 10 Log[\frac{I}{I_o} ]\\\\](https://tex.z-dn.net/?f=dB%20%3D%2010%20Log%5B%5Cfrac%7BI%7D%7BI_o%7D%20%5D%5C%5C%5C%5C)
where;
I₀ is threshold of hearing = 1 x 10⁻¹² W/m²
I is intensity of the sound in W/m²
Substitute the given values and for I;
![dB = 10 Log[\frac{I}{I_o} ]\\\\60 = 10 Log[\frac{I}{I_o} ]\\\\6 = Log[\frac{I}{I_o} ]\\\\10^6 = \frac{I}{I_o} \\\\I = 10^6 \ \times \ I_o\\\\I = 10^6 \ \times \ 1^{-12} \ W/m^2 \\\\I = 1\ \times \ 10^{-6} \ W/m^2](https://tex.z-dn.net/?f=dB%20%3D%2010%20Log%5B%5Cfrac%7BI%7D%7BI_o%7D%20%5D%5C%5C%5C%5C60%20%3D%2010%20Log%5B%5Cfrac%7BI%7D%7BI_o%7D%20%5D%5C%5C%5C%5C6%20%3D%20%20Log%5B%5Cfrac%7BI%7D%7BI_o%7D%20%5D%5C%5C%5C%5C10%5E6%20%3D%20%5Cfrac%7BI%7D%7BI_o%7D%20%5C%5C%5C%5CI%20%3D%2010%5E6%20%5C%20%5Ctimes%20%5C%20I_o%5C%5C%5C%5CI%20%3D%2010%5E6%20%5C%20%5Ctimes%20%5C%201%5E%7B-12%7D%20%5C%20W%2Fm%5E2%20%5C%5C%5C%5CI%20%3D%201%5C%20%5Ctimes%20%5C%2010%5E%7B-6%7D%20%5C%20W%2Fm%5E2)
Therefore, the intensity of the sound in W/m² is 1 x 10⁻⁶ W/m².
Answer:
In this case, a body of mass 5 kg kept at a height of 10 m. So the potential energy is given as 5 * 10 *10 = 500 J.
