In the process of changing a flat tire, a motorist uses a hydraulic jack. She begins by applying a force of 58 N to the input pi

ston, which has a radius r1. As a result, the output plunger, which has a radius r2, applies a force to the car. The ratio r2/r1 has a value of 8.2. Ignore the height difference between the input piston and output plunger and determine the force that the output plunger applies to the car.

1 answer:

AfilCa [17]3 years ago

6 0

Answer:

The correct answer is "3899.92 N".

Explanation:

The given values are:

Force,

$F_{app}=58 N$

Ratio,

$\frac{R_2}{R_1}=8.2$

As we know,

Area, $A=\pi r^2$

or,

⇒ $\frac{F_2}{F_1} =\frac{A_2}{A_1}$

On substituting the value of "A", we get

⇒ $\frac{F_2}{F_1} =\frac{\pi r_2^2}{\pi r_1^2}$

⇒ $\frac{F_2}{F_1} =\frac{r_2^2}{r_1^2}$

On applying cross-multiplication, we get

⇒ $F_2=F_1\times (\frac{r_2}{r_1} )^2$

On substituting the given values, we get

⇒ $=58\times (8.2)^2$

⇒ $=58\times 67.2$

⇒ $=3899.92 \ N$

You might be interested in

Light is polarized by using:

maxonik [38]

Answer:

Polaroid fliter

Explanation:

light can be polarized by using Polaroid filters

Polaroid fliter are made of special material that is capable of blocking one of the two planes of vibration of an electromagnetic wave

hope this is useful--(have a good day)

8 0

3 years ago

a car goes from a velocity zero to a velocity of 15 meters per second East in 2.1 seconds. What is the car's acceleration?

leva [86]

31.5 would be the acceleration.

3 0

3 years ago

A compact disc (CD) stores music in a coded pattern of tiny pits 10−7m deep. The pits are arranged in a track that spirals outwa

andreev551 [17]

(a) 50 rad/s

The angular speed of the CD is related to the linear speed by:

$\omega=\frac{v}{r}$

where

$\omega$ is the angular speed

v is the linear speed

r is the distance from the centre of the CD

When scanning the innermost part of the track, we have

v = 1.25 m/s

r = 25.0 mm = 0.025 m

Therefore, the angular speed is

$\omega=\frac{1.25 m/s}{0.025 m}=50 rad/s$

(b) 21.6 rad/s

As in part a, the angular speed of the CD is given by

$\omega=\frac{v}{r}$

When scanning the outermost part of the track, we have

v = 1.25 m/s

r = 58.0 mm = 0.058 m

Therefore, the angular speed is

$\omega=\frac{1.25 m/s}{0.058 m}=21.6 rad/s$

(c) 5550 m

The maximum playing time of the CD is

$t =74.0 min \cdot 60 s/min = 4,440 s$

And we know that the linear speed of the track is

v = 1.25 m/s

If the track were stretched out in a straight line, then we would have a uniform motion, therefore the total length of the track would be:

$d=vt=(1.25 m/s)(4,440 s)=5,550 m$

(d) $-6.4\cdot 10^{-3} rad/s^2$

The angular acceleration of the CD is given by

$\alpha = \frac{\omega_f - \omega_i}{t}$

where

$\omega_f = 21.6 rad/s$ is the final angular speed (when the CD is scanned at the outermost part)

$\omega_i = 50.0 rad/s$ is the initial angular speed (when the CD is scanned at the innermost part)

$t=4440 s$ is the time elapsed

Substituting into the equation, we find

$\alpha=\frac{21.6 rad/s-50.0 rad/s}{4440 s}=-6.4\cdot 10^{-3} rad/s^2$

5 0

3 years ago

Read 2 more answers

A train moves moves from rest to a speed of 25 m/s in 30.0 sec . what is its acceleration

spayn [35]

A = Delta v/Delta t
Delta v = 25 - 0 = 25
Delta t = 30
25/30 = 5/6 = 1.66 repeating

7 0

3 years ago

Read 2 more answers

Two asteroids collide and stick together. The first asteroid has a mass of 15\times 10^3\,\mathrm{kg}15×10 3 kg and is initially

statuscvo [17]

Answer:

Final speed is 900.06 m/s at $0.2215^{\circ}$

Solution:

As per the question:

Mass of the first asteroid, m = $15\times 10^{3}\kg$

Mass of the second asteroid, m' = $20\times 10^{3}\kg$

Initial velocity of the first asteroid, v = 770 m/s

Initial velocity of the second asteroid, v' = 1020 m/s

Angle between the two initial velocities, $\theta = 20^{\circ}$

Now,

Since, the velocities and hence momentum are vector quantities, then by the triangle law of vector addition of 2 vectors A and B, the resultant is given by:

$\vec{R} = \sqrt{A^{2} + 2ABcos\theta + B^{2}}$

Thus applying vector addition and momentum conservation, the final velocity is given by:

$(m + m')v_{final} = \sqrt{(mv)^{2} + 2(mv)(m'v')cos20^{\circ} + (m'v')^{2}}$ (1)

Now,

$(m +m')v_{final} = (35\times 10^{3})v_{final}$

$(mv)^{2} = (15\times 10^{3}\times 770)^{2} = 1.334\times 10^{14}$

$(m'v')^{2} = (20\times 10^{3}\times 1020)^{2} = 4.16\times 10^{14}$

$2(mv)(m'v')cos20^{\circ} = 2(15\times 10^{3}\times 770)(20\times 10^{3}\times 1020)cos20^{\circ} = 4.43\times 10^{14}$

Now, substituting the suitable values in eqn (1), we get:

$v_{final} = 900.06\ m/s$

Now, the direction for the two vectors is given by:

$\theta = sin^{- 1} \frac{m'v'sin20^{\circ}}{(m + m')v_{final}}$

$\theta = sin^{- 1} \frac{20\times 10^{3}\times 1020sin20^{\circ}}{(35\times 10^{3})\times 900.06} = 0.2215^{\circ}$

5 0

3 years ago
