Answer:
I don't know sorry For this question
Answer:
a) 0.1832 A
b) 11.91 Volts
c) 2.18 Watt , 0.0168 Watt
Explanation:
(a)
R = external resistor connected to the terminals of the battery = 65 Ω
E = Emf of the battery = 12.0 Volts
r = internal resistance of the battery = 0.5 Ω
i = current flowing in the circuit
Using ohm's law
E = i (R + r)
12 = i (65 + 0.5)
i = 0.1832 A
(b)
Terminal voltage is given as
= i R
= (0.1832) (65)
= 11.91 Volts
(c)
Power dissipated in the resister R is given as
= i²R
= (0.1832)²(65)
= 2.18 Watt
Power dissipated in the internal resistance is given as
= i²r
= (0.1832)²(0.5)
= 0.0168 Watt
Answer:
33 N
Explanation:
v = Velocity of fluid = 8+2 = 10 m/s
= Density of fluid = 1.2 kg/m³
C = Coefficient of drag = 1.1
A = Cross sectional area = 0.5 m²
Drag force is given by

The drag force on the athlete is 33 N
Answer:
a

b

c
Explanation:
From the question we are told that
The angle of incidence is
The refractive index of water is
Generally Snell's law is mathematically represented as

Here
is the refractive index of air with value
is the angle of refraction
So
![\theta _2 = sin^{-1}[\frac{n_1 * sin(\theta _1)}{n_2} ]](https://tex.z-dn.net/?f=%5Ctheta%20_2%20%20%3D%20%20sin%5E%7B-1%7D%5B%5Cfrac%7Bn_1%20%2A%20sin%28%5Ctheta%20_1%29%7D%7Bn_2%7D%20%5D)
=> ![\theta _2 = sin^{-1}[\frac{1.3 * sin(10)}{1} ]](https://tex.z-dn.net/?f=%5Ctheta%20_2%20%20%3D%20%20sin%5E%7B-1%7D%5B%5Cfrac%7B1.3%20%2A%20sin%2810%29%7D%7B1%7D%20%5D)
=>
Given that the angle should not be greater than
then the angle of incidence will be
![\theta _1 = sin^{-1}[\frac{n_2 * sin(\theta _2)}{n_1} ]](https://tex.z-dn.net/?f=%5Ctheta%20_1%20%20%3D%20%20sin%5E%7B-1%7D%5B%5Cfrac%7Bn_2%20%2A%20sin%28%5Ctheta%20_2%29%7D%7Bn_1%7D%20%5D)
=> ![\theta _1 = sin^{-1}[\frac{1 * sin(45)}{1.3} ]](https://tex.z-dn.net/?f=%5Ctheta%20_1%20%20%3D%20%20sin%5E%7B-1%7D%5B%5Cfrac%7B1%20%2A%20sin%2845%29%7D%7B1.3%7D%20%5D)
=>
Generally for critical angle is mathematically represented as
![\theta_c = sin^{-1}[\frac{n_2}{n_1} ]](https://tex.z-dn.net/?f=%5Ctheta_c%20%20%3D%20%20sin%5E%7B-1%7D%5B%5Cfrac%7Bn_2%7D%7Bn_1%7D%20%5D)
=>
=>
