Solved, can someone check it over!

Physics

1 answer:

kakasveta [241]2 years ago

4 0

Answer:

its good no need to change anything :))

You might be interested in

1 point

Yuliya22 [10]

PE= 3kg x 10N/kg x 10m
= 300J

8 0

3 years ago

I NEED HELP PLEASE, THANKS! :)

mrs_skeptik [129]

Answer:

1. Largest force: C; smallest force: B; 2. ratio = 9:1

Explanation:

The formula for the force exerted between two charges is

$F=K\dfrac{ q_{1}q_{2}}{r^{2}}$

where K is the Coulomb constant.

q₁ and q₂ are also identical and constant, so Kq₁q₂ is also constant.

For simplicity, let's combine Kq₁q₂ into a single constant, k.

Then, we can write

$F=\dfrac{k}{r^{2}}$

1. Net force on each particle

Let's

Call the distance between adjacent charges d.
Remember that like charges repel and unlike charges attract.

Define forces exerted to the right as positive and those to the left as negative.

(a) Force on A

$\begin{array}{rcl}F_{A} & = & F_{B} + F_{C} + F_{D}\\& = & -\dfrac{k}{d^{2}} - \dfrac{k}{(2d)^{2}} +\dfrac{k}{(3d)^{2}}\\& = & \dfrac{k}{d^{2}}\left(-1 - \dfrac{1}{4} + \dfrac{1}{9} \right)\\\\& = & \dfrac{k}{d^{2}}\left(\dfrac{-36 - 9 + 4}{36} \right)\\\\& = & \mathbf{-\dfrac{41}{36} \dfrac{k}{d^{2}}}\\\\\end{array}$

(b) Force on B

$\begin{array}{rcl}F_{B} & = & F_{A} + F_{C} + F_{D}\\& = & \dfrac{k}{d^{2}} - \dfrac{k}{d^{2}} + \dfrac{k}{(2d)^{2}}\\& = & \dfrac{k}{d^{2}}\left(\dfrac{1}{4} \right)\\\\& = &\mathbf{\dfrac{1}{4} \dfrac{k}{d^{2}}}\\\\\end{array}$

(C) Force on C

$\begin{array}{rcl}F_{C} & = & F_{A} + F_{B} + F_{D}\\& = & \dfrac{k}{(2d)^{2}} + \dfrac{k}{d^{2}} + \dfrac{k}{d^{2}}\\& = & \dfrac{k}{d^{2}}\left( \dfrac{1}{4} +1 + 1 \right)\\\\& = & \dfrac{k}{d^{2}}\left(\dfrac{1 + 4 + 4}{4} \right)\\\\& = & \mathbf{\dfrac{9}{4} \dfrac{k}{d^{2}}}\\\\\end{array}$

(d) Force on D

$\begin{array}{rcl}F_{D} & = & F_{A} + F_{B} + F_{C}\\& = & -\dfrac{k}{(3d)^{2}} - \dfrac{k}{(2d)^{2}} - \dfrac{k}{d^{2}}\\& = & \dfrac{k}{d^{2}}\left( -\dfrac{1}{9} - \dfrac{1}{4} -1 \right)\\\\& = & \dfrac{k}{d^{2}}\left(\dfrac{-4 - 9 -36}{36} \right)\\\\& = & \mathbf{-\dfrac{49}{36} \dfrac{k}{d^{2}}}\\\\\end{array}$

(e) Relative net forces

In comparing net forces, we are interested in their magnitude, not their direction (sign), so we use their absolute values.

$F_{A} : F_{B} : F_{C} : F_{D} = \dfrac{41}{36} : \dfrac{1}{4} : \dfrac{9}{4} : \dfrac{49}{36}\ = 41 : 9 : 81 : 49\\\\\text{C experiences the largest net force.}\\\text{B experiences the smallest net force.}\\$

2. Ratio of largest force to smallest

$\dfrac{ F_{C}}{ F_{B}} = \dfrac{81}{9} = \mathbf{9:1}\\\\\text{The ratio of the largest force to the smallest is $\large \boxed{\mathbf{9:1}}$}$

7 0

3 years ago

How much water will flow in 30 secs through 200 mm of capillary tube of 1.50 mm in diameter, if the pressure difference across t

Paladinen [302]

The water outflow in 30 secs through 200 mm of the capillary tube is mathematically given as

$Qo=1.6 \times 10^{2} \mathrm{~mL}$

<h3>What is the water outflow in 30 secs through 200 mm of the capillary tube?</h3>

$\begin{aligned}\Delta P &=6660 \mathrm{~m} / \mathrm{m}^{2} \\\mu &=8.01 \times 10^{-4} \text { Pas } \\t &=30 \mathrm{~s} \\L &=200 \mathrm{~mm}=200 \times 10^{-3} \mathrm{~m} \\D &=1.5 \mathrm{~mm}=1.5 \times 10^{-3} \mathrm{~m} \Rightarrow \gamma=\frac{1.5 \times 10^{-3}}{2} \mathrm{~m}\end{aligned}$
