Let original length be L. The new length is therefore 4L.
Let original cross sectional surface area of the wire be equal to πr^2.
This means original volume was L x πr^2 = Lπr^2
The volume is the same but the length is different so 4L x new surface area must be equal to Lπr^2. Let new surface area be equal to Y.
4L x Y = Lπr^2
=> Y = (πr^2 )/ 4
Using the resistivity formula,
R = pL/A. p which is resistivity is a constant so it stays the same
But this time, instead of L we have 4L and instead of πr^2 we have (πr^2)/4.
so the new resistance
= (4Lp)/ {(πr^2)/4}
= 16 (pL)/(πr^2)
= 16 (pL)/A. because πr^2 is A
since pL/A is equal to R from the formula, this is equal to
16 R.
R was 10 ohms
therefore new resistance is 16 x 10 = 160 ohms
1Draw a quick sketch of the object.
2Draw an arrow showing every force acting on the object.
3<span>To calculate the net force, add any vectors acting on the same axis (x and y), making sure to pay attention to the directions.
Hope this helps :)
</span>
The believe the answer to this is B
Answer:
is reflected back into the region of higher index
Explanation:
Total internal reflection is a phenomenon that occurs when all the light passing from a region of higher index of refraction to a region of lower index is reflected back into the region of higher index.
According to Snell's law, refraction of ligth is described by the equation
where
n1 is the refractive index of the first medium
n2 is the refractive index of the second medium
is the angle of incidence (in the first medium)
is the angle of refraction (in the second medium)
Let's now consider a situation in which
so light is moving from a medium with higher index to a medium with lower index. We can re-write the equation as
Where
is a number greater than 1. This means that above a certain value of the angle of incidence , the term on the right can become greater than 1. So this would mean
But this is not possible (the sine cannot be larger than 1), so no refraction occurs in this case, and all the light is reflected back into the initial medium (total internal reflection). The value of the angle of incidence above which this phenomen occurs is called critical angle, and it is given by
Answer: c. displacement
Explanation:
Let's begin by stating clear that motion is the change of position of a body at a certain time. So, during this motion, the body will have a trajectory and a displacement.
In the specific case of the displacement, it is defined as the distance in a straight line between the initial and final position (is a vector magnitude).
Therefore:
Displacement s the the change in position relative to an initial location.
