Ostrovityanka [42]
3 years ago
8

A. For a 200g load acting vertically downwards at point B’, determine the axial load in members A’B’, B’C’, B’D’, C’D’ and C’E’.

Engineering
1 answer:
Nonamiya [84]3 years ago
7 0

Answer:

attached below

Explanation:

You might be interested in
A glass tube is inserted into a flowing stream of water with one opening directed upstream and the other end vertical. If the wa
Furkat [3]

Answer:

h=0.46m

Explanation:

From the question we are told that:

Velocity of water V=3m/s

Height=?

Generally, the equation for Water Velocity is mathematically given by

V=\sqrt{2gh}

Therefore Height h is given as

h=\frac{v}{2g}

h=\frac{3^2}{2*9.81}

h=0.46m

5 0
3 years ago
What are the two reasons for a clear cut
Inessa [10]

Answer:

to clear land for agriculture and settlement and to use or sell timber for lumber, paper products, or fuel.

3 0
2 years ago
The waffle slab is: a) the two-way concrete joist framing system. b) a one-way floor and roof framing system. c) the one-way con
GREYUIT [131]

Answer:

a) the two-way concrete joist framing system

Explanation:

A waffle slab is also known as ribbed slab, it is a slab which as waffle like appearance with holes beneath. It is adopted in construction projects that has long length, length more than 12m. The waffle slab is rigid, therefore it is used in building that needs minimal vibration.

4 0
3 years ago
What are the maximum weights for single, tandem and 5-axle combinations?
belka [17]
Hauling Vehicles that include a semitrailer manufactured prior to or in the model year of 2024, and registered in Illinois prior to January 1, 2025, having 5 axles with a distance of 42 feet or less between extreme axles, may not exceed the following maximum weights: 20,000 pounds on a single axle; 34,000 pounds
7 0
3 years ago
Steam at a pressure of 100 bar and temperature of 600 °C enters an adiabatic nozzle with a velocity of 35 m/s. It leaves the noz
butalik [34]

Answer:

Exit velocity V_2=1472.2 m/s.

Explanation:

Given:

At inlet:

P_1=100 bar,T_=600°C,V_1=35m/s

Properties of steam at 100 bar and 600°C

        h_1=3624.7\frac{KJ}{Kg}

At exit:Lets take exit velocity V_2

We know that if we know only one property inside the dome  then we will find the other property by using steam property table.

Given that dryness or quality of steam at the exit of nozzle  is 0.85 and pressure P=80 bar.So from steam table we can find the other properties.

Properties of saturated steam at 80 bar

   h_f= 1316.61\frac{KJ}{Kg} ,h_g= 2757.8\frac{KJ}{Kg}

So the enthalpy of steam at the exit of turbine

h_2=h_f+x(h_g-h_f)\frac{KJ}{Kg}

h_2=1316.61+0.85(2757.8-1316.61)\frac{KJ}{Kg}

 h_2=2541.62\frac{KJ}{Kg}

Now from first law for open system

h_1+\dfrac{V_1^2}{2}+Q=h_2+\dfrac{V_2^2}{2}+w

In the case of adiabatic nozzle Q=0,W=0

3624.7+\dfrac{35^2}{2000}+0=2541.62+\dfrac{(V_2)^2}{2000}+0

V_2=1472.2 m/s

So Exit velocity V_2=1472.2 m/s.

4 0
3 years ago
