A metallic material with yield stress of 140 MPa and cross section of 300 mm x 100 mm, is subjected to a tensile force of 8.00 M

N. Will the sample experience plastic deformation? You must justify your answer.

1 answer:

Readme [11.4K]3 years ago

8 0

Answer:Yes,266.66 MPa

Explanation:

Given

Yield stress of material =140 MPa

Cross-section of $300\times 100 mm^2$

Force(F)=8 MN

Therefore stress due to this Force( $\sigma$ )

$\sigma =\frac{F}{A}=\frac{8\times 10^6}{300\times 100\times 10^{-6}}$

$\sigma =266.66 \times 10^{6} Pa$

$\sigma =266.66 MPa$

Since induced stress is greater than Yield stress therefore Plastic deformation occurs
