Higher voltage means faster rotation. Changing the voltage polarity changes the direction of the motor.
<span>Newton's law of gravitation is attractive, whereas Coulomb's law is attractive or repulsive. Both are proportional to the inverse square of distance.</span>
Answer:
Graph for object that is not moving: B
Graph for object that is speeding up: D
Explanation:
A.) In order to represent that an object is not moving, you must either show that there is no velocity (0 m/s) or show a position over time graph that is a horizontal line.
Because the position is the same as time increases, the graph shows that there the object must be at rest, as there is no change in position due to velocity. (Velocity must be 0m/s)
B.) In order to represent an object is speeding up, the position time graph must either be a positive exponential function, the velocity time graph must be a positive, linear line, or the acceleration over time graph must be a positive, horizontal line.
Why is D the correct answer? Because if an object is speeding up, you know that the value of its speed (velocity) is increasing at some rate. And since speeding up refers to positive change, the function of velocity over time graph must be a positive function.
Answer:
= 285 Joules
Explanation:
a) answer can be found out in attachment
(b) The temperature for the isothermal compression is the same as the temp at the end of the isobaric expansion. Since pressure is held constant but volume doubles, we use the ideal gas law:
p V = nR T to see that the temperature also doubles.
.So... temp for isothermal compression = 355×2 = 710 K
.(c) The max pressure occurs at the top point. At this point, the volume is back to the original value but the temperature is twice the original value. So the pressure at this point is twice the original, or
max pressure = 2×240000 Pa = 480000 Pa = 4.80 x 10^5 Pa
(d) total work done by the piston = workdone during isothermal compression - work done during expansion =
= nRT ln(V initial / V final)-p (V initial - V final)
= nRT ln(2) - nR(T final - T initial)
= 0.250× 8.314 ×710×ln(2)-0.250×8.314× (710 - 355)
= 285 Joules
Answer:
31250 meters
Explanation:
Given data
Intitially at rest, the velocity will be
u= 0m/s
acceleration a= 25m/s^2
Time= 50s
We know that the expression for the displacement is given as
S=U+ 1/2at^2
S= 0+ 1/2*25*50^2
S= 12.5*2500
S=31250 meters
Hence the displacement is 31250 meters
