Mandarinka [93]
4 years ago
5

A section of highway has a speed-flow relationship of the form . What is the capacity of the highway section, the speed at capac

ity, and the density when the highway is at one-quarter of the capacity? (15 pts)

Engineering
1 answer:
denis23 [38]4 years ago
6 0

Answer:

The capacity of the highway section = 400 vehicle/hr

The capacity of the highway section = 40 km/hr

The density when the highway is at one-quarter of the capacity = 13.39 vehicle/km

Explanation:

See attached pictures.

You might be interested in
Which of the following is not a task electricians typically do when maintaining a building’s electrical system?
Scorpion4ik [409]

Answer:replace insulation to help control...

Explanation:

Thats a insulation workers job

4 0
3 years ago
A cylindrical specimen of a metal alloy 48.8 mm long and 9.09 mm in diameter is stressed in tension. A true stress of 327 MPa ca
Gnom [1K]

Answer:

The true stress necessary to plastically elongate the specimen is 406.69MPa

Explanation:

The Explanation or Solving is on the attached document.

5 0
3 years ago
Consider a multiprocessor system and a multithreaded program written using the many-to-many threading model. Let the number of u
Montano1993 [528]

Answer:

At the point when the quantity of bit strings is not exactly the quantity of processors, at that point a portion of the processors would stay inert since the scheduler maps just part strings to processors and not client level strings to processors. At the point when the quantity of part strings is actually equivalent to the quantity of processors, at that point it is conceivable that the entirety of the processors may be used all the while. Be that as it may, when a part string obstructs inside the portion (because of a page flaw or while summoning framework calls), the comparing processor would stay inert. When there are more portion strings than processors, a blocked piece string could be swapped out for another bit string that is prepared to execute, in this way expanding the use of the multiprocessor system.When the quantity of part strings is not exactly the quantity of processors, at that point a portion of the processors would stay inert since the scheduler maps just bit strings to processors and not client level strings to processors. At the point when the quantity of bit strings is actually equivalent to the quantity of processors, at that point it is conceivable that the entirety of the processors may be used at the same time. Be that as it may, when a part string hinders inside the piece (because of a page flaw or while summoning framework calls), the relating processor would stay inert. When there are more portion strings than processors, a blocked piece string could be swapped out for another bit string that is prepared to execute, along these lines expanding the usage of the multiprocessor framework.

4 0
3 years ago
Steam enters a turbine operating at steady state at 2 MPa, 323 °C with a velocity of 65 m/s. Saturated vapor exits at 0.1 MPa an
Lera25 [3.4K]

Answer:

\dot Q_{out} = 13369.104\,kW

Explanation:

The turbine is modelled after the First Law of Thermodynamics:

-\dot Q_{out} - \dot W_{out} + \dot H_{in} - \dot H_{out} + \dot K_{in} - \dot K_{out} + \dot U_{in} - \dot U_{out} = 0

The rate of heat transfer between the turbine and its surroundings is:

\dot Q_{out} = \dot H_{in}-\dot H_{out} + \dot K_{in} - \dot K_{out} - \dot W_{out} + \dot U_{in} - \dot U_{out}

The specific enthalpies at inlet and outlet are, respectively:

h_{in} = 3076.41\,\frac{kJ}{kg}

h_{out} = 2675.0\,\frac{kJ}{kg}

The required output is:

\dot Q_{out} = \left(8\,\frac{kg}{s} \right)\cdot \left\{3076.41\,\frac{kJ}{kg}-2675.0\,\frac{kJ}{kg}+\frac{1}{2}\cdot \left[\left(65\,\frac{m}{s} \right)^{2}-\left(42\,\frac{m}{s} \right)^{2}\right] + \left(9.807\,\frac{m}{s^{2}} \right)\cdot (4\,m) \right\} - 8000\,kW\dot Q_{out} = 13369.104\,kW

4 0
3 years ago
Read the following statement.
alekssr [168]
The correct answer is A
5 0
4 years ago
