A car is driven 110 km west and then 40 km southwest, how far is the car from the point of origin?

1 answer:

Margaret [11]3 years ago

8 0

Answer:

141.147 km

Explanation:

$sin45=\frac{BD}{BC}\\\Rightarrow BD=BCsin45\\\Rightarrow BD=40\times sin45\\\Rightarrow BD=28.28\ km$

Now, AE=BD also CD=BD as the angle B and C are equal

So, from Pythagoras theorem

AC² = AE²+(CD+DE)²

$AC=\sqrt{AE^2+(CD+DE)^2}\\\Rightarrow AC=\sqrt{(40\times sin45)^2+(110+40\times sin45)^2}\\\Rightarrow AC=141.147\ km$

Displacement of the car is 141.147 km

You might be interested in

The horizontal beam in Fig. E11.14 weighs 190 N, and its center of gravity is at its center. Find (a) the tension in the cable a

grandymaker [24]

Answer:

(a). The tension in the cable is 658.33 N.

(b). The horizontal components of the force exerted on the beam at the wall is 526.66 N.

(c). The vertical components of the force exerted on the beam at the wall is 95.002 N.

Explanation:

Given that,

Weight of beam= 190 N

Here, The center of gravity is at its center

According to figure,

The angle is

$\sin\theta=\dfrac{3}{5}$

The horizontal component is

$T_{x}=T\cos\theta$

The vertical component is

$T_{y}=T\sin\theta$

(a). We need to calculate the tension in the cable

Using formula of net torque acting on the pivot

$\sum\tau=F_{b}\times r+F_{w}\times r'-T\sin \theta\times r'$

Put the value into the formula

$0=190\times2+300\times 4-T\sin\theta\times 4$

$T\sin\theta\times 4=380+1200$

$T=\dfrac{1580\times5}{3\times 4}$

$T=658.33\ N$

(b). We need to calculate the horizontal components of the force exerted on the beam at the wall

Using formula of horizontal component

$F_{x}=T\cos\theta$

Put the value into the formula

$F_{x}=658.33\times\dfrac{4}{5}$

$F_{x}=526.66\ N$

(c). We need to calculate the vertical components of the force exerted on the beam at the wall

Using formula of vertical component

$F_{y}=F_{b}+F_{w}-T\sin\theta$

Put the value into the formula

$F_{y}=190+300-658.33\times\dfrac{3}{5}$

$F_{y}=95.002\ N$

Hence, (a). The tension in the cable is 658.33 N.

(b). The horizontal components of the force exerted on the beam at the wall is 526.66 N.

(c). The vertical components of the force exerted on the beam at the wall is 95.002 N.

3 0

3 years ago

A mixture in which the parts can be seen separately from the other parts is considered to be what type of mixture

serious [3.7K]

Answer: A mixture is a combination of two or more substances (elements or compounds) which is not done chemically. Mixtures are two types Homogeneous Mixtures and Heterogeneous mixtures.

6 0

3 years ago

The law of mass action suggests that _____.

Nostrana [21]

the higher concentration of molecules, the faster a reaction can occur

7 0

3 years ago

Read 2 more answers

Please help, it's super easy!

Alexandra [31]

The moon's gravitational pull on Earth causes water to bulge on two sides of the Earth(#3)

https://scijinks.gov/tides/

5 0

3 years ago

Read 2 more answers

A stretched string has a mass per unit length of 5.40 g/cm and a tension of 17.5 N. A sinusoidal wave on this string has an ampl

kondaur [170]

Answer:

Part a)

$y_m = 0.157 mm$

part b)

$k = 101.8 rad/m$

Part c)

$\omega = 579.3 rad/s$

Part d)

here since wave is moving in negative direction so the sign of $\omega$ must be positive

Explanation:

As we know that the speed of wave in string is given by

$v = \sqrt{\frac{T}{m/L}}$

so we have

$T = 17.5 N$

$m/L = 5.4 g/cm = 0.54 kg/m$

now we have

$v = \sqrt{\frac{17.5}{0.54}}$

$v = 5.69 m/s$

now we have

Part a)

$y_m$ = amplitude of wave

$y_m = 0.157 mm$

part b)

$k = \frac{\omega}{v}$

here we know that

$\omega = 2\pi f$

$\omega = 2\pi(92.2) = 579.3 rad/s$

so we have

$k = \frac{579.3}{5.69}$

$k = 101.8 rad/m$

Part c)

$\omega = 579.3 rad/s$

Part d)

here since wave is moving in negative direction so the sign of $\omega$ must be positive

4 0
