professor190 [17]
3 years ago
6

A lagoon is designed to accommodate an input flow of 0.10 m^3/s of nonconservative pollutant with concentration 30 mg/L and deca

y coefficient of 0.2/day. The effluent from the lagoon must have pollutant concentration of less than 10 mg/L. How large is the lagoon (assume complete mixing)?
Engineering
1 answer:
dexar [7]3 years ago
5 0

Answer:

Volume of the lagoon required for the decay process must be larger than 86580 m³ = 8.658 × 10⁷ L

Explanation:

The lagoon can be modelled as a Mixed flow reactor.

From the value of the decay constant (0.2/day), one can deduce that the decay reaction of the pollutant is a first order reaction.

The performance equation of a Mixed flow reactor is given from the material and component balance thus:

(V/F₀) = (C₀ - C)/((C₀)(-r)) (From the Chemical Reaction Engineering textbook, authored by Prof. Octave Levenspiel)

V = volume of the reactor (The lagoon) = ?

C₀ = Initial concentration of the reactant (the pollutant concentration) = 30 mg/L = 0.03 mg/m³

F₀ = Initial flow rate of reactant in mg/s = 0.10 m³/s × C₀ = 0.1 m³/s × 0.03 mg/m³ = 0.003 mg/s

C = concentration of reactant at any time; effluent concentration < 10mg/L, this means the maximum concentration of pollutant allowed in the effluent is 10 mg/L

For the sake of easy calculation, C = the maximum value = 10 mg/L = 0.01 mg/m³

(-r) = kC (Since we know this decay process is a first order reaction)

This makes the performance equation to be:

(kVC₀/F₀) = (C₀ - C)/C

V = F₀(C₀ - C)/(kC₀C)

k = 0.2/day = 0.2/(24 × 3600s) = 2.31 × 10⁻⁶/s

V = 0.003(0.03 - 0.01)/(2.31 × 10⁻⁶ × 0.03 × 0.01)

V = 86580 m³

Since this calculation is made for the maximum concentration of 10mg/L of pollutant in the effluent, the volume obtained is the minimum volume of reactor (lagoon) to ensure a maximum volume of 10 mg/L of pollutant is contained in the effluent.

The lower the concentration required for the pollutant in the effluent, the larger the volume of reactor (lagoon) required for this decay reaction. (Provided all the other parameters stay the same)

Hope this helps!

You might be interested in
A commuter train traveling at 50 mi/h is 3 mi from a station. The train then decelerates so that its speed is 15 mi/h when it is
jonny [76]

Answer:

a) t = 277.477\,s\,(4.625\min), b) v_{f} = 0\,\frac{mi}{h}, c) a = -0.128\,\frac{ft}{s^{2}}

Explanation:

a) The deceleration experimented by the commuter train in the first 2.5 miles is:

a=\frac{[(15\,\frac{mi}{h} )\cdot (\frac{5280\,ft}{1\,mi} )\cdot (\frac{1\,h}{3600\,s} )]^{2}-[(50\,\frac{mi}{h} )\cdot (\frac{5280\,ft}{1\,mi} )\cdot (\frac{1\,h}{3600\,s} )]^{2}}{2\cdot (2.5\,mi)\cdot (\frac{5280\,ft}{1\,mi} )}

a = -0.185\,\frac{ft}{s^{2}}

The time required to travel is:

t = \frac{(15\,\frac{mi}{h} )\cdot (\frac{5280\,ft}{1\,fi} )\cdot(\frac{1\,h}{3600\,s} )-(50\,\frac{mi}{h} )\cdot (\frac{5280\,ft}{1\,fi} )\cdot(\frac{1\,h}{3600\,s} )}{-0.185\,\frac{ft}{s^{2}} }

t = 277.477\,s\,(4.625\min)

b) The commuter train must stop when it reaches the station to receive passengers. Hence, speed of train must be v_{f} = 0\,\frac{mi}{h}.

c) The final constant deceleration is:

a = \frac{(0\,\frac{mi}{h} )\cdot (\frac{5280\,ft}{1\,mi} )\cdot(\frac{1\,h}{3600\,s} )-(15\,\frac{mi}{h} )\cdot (\frac{5280\,ft}{1\,mi} )\cdot(\frac{1\,h}{3600\,s} )}{(2.875\,min)\cdot (\frac{60\,s}{1\,min} )}

a = -0.128\,\frac{ft}{s^{2}}

7 0
3 years ago
Technician A says that the most commonly used combustion chamber types include hemispherical, and wedge. Technician B says that
Inessa05 [86]

Answer:

Technician A and Technician B both are correct.

Explanation:

Technician A accurately notes that perhaps the forms of combustion process most widely used are hemispherical and cross.

Technician B also correctly notes that in several cylinder heads, cooling system and greases gaps and pathways are found.

6 0
3 years ago
Mohr's circle represents: A Orientation dependence of normal and shear stresses at a point in mechanical members B The stress di
blsea [12.9K]

Answer:

The correct answer is A : Orientation dependence of normal and shear stresses at a point in mechanical members

Explanation:

Since we know that in a general element of any loaded object the normal and shearing stresses vary in the whole body which can be mathematically represented as

\sigma _{x'x'}=\frac{\sigma _{xx}+\sigma _{yy}}{2}+\frac{\sigma _{xx}-\sigma _{yy}}{2}cos(2\theta )+\tau _{xy}sin(2\theta )

And \tau _{x'x'}=-\frac{\sigma _{xx}-\sigma _{yy}}{2}sin(2\theta )+\tau _{xy}cos(2\theta )

Mohr's circle is the graphical representation of the variation represented by the above 2 formulae in the general oriented element of a body that is under stresses.

The Mohr circle is graphically displayed in the attached figure.

4 0
3 years ago
The enforcement of OSHA standards is provided by federal and state
Gnoma [55]

Answer:

Explanation:

Enforcing OSHA, Occupational Safety and Health Administration, standards is not a job for electricians, lawmakers or tax collectors. The right answer is safety inspectors.

3 0
2 years ago
A car is traveling at sea level at 78 mi/h on a 4% upgrade before the driver sees a fallen tree in the roadway 150 feet away. Th
Dmitrij [34]

Answer: V = 47.7 mi/hr

Explanation:

first we calculate elements of aero-dynamic resistance

Ka = p/2 * CD * A.f

p is the density of air(0.002378 slugs/ft^3) for zero altitude, CD is the drag coefficient(0.35) and A.f is the front region of the vehicle

so we substitute

Ka = 0.002378/2 * 0.35 * 18

Ka = 0.00749

Now we calculate the final speed of the vehicle (V2) using the relation;

S = (YbW/2gKa)In[ (UW + KaV1^2 + FriW ± Wsinθg) / (UW + KaV2^2 + FriW ± Wsinθg)

so

WE SUBSTITUTE

150 = (1.04 * 2700 / 2 * 32.2 * 0.0075) In [(0.8 * 2700 + 0.0075 *(78mil/hr * 5280ft/1min * 1hr/3600s)^2 + 0.017 * 2700 ± 2700 * 0.04) / (0.8 * 2700 + 0.0075 * V2^2 + 0.017 * 2700 ± 2700 * 0.04)]

150 = (2808/0.483) In [(2160 + 98.16 + 153.9) / ( 2160 + 0.0075V2^2 + 153.9)]

150 = 5813.66 In [ (2160 + 98.16 + 153.9) / ( 2160 + 0.0075V2^2 + 153.9)]

divide both sides by 5813.66

0.0258 = In [ (2412.06) / ( 0.0075V2^2 + 2313.9)]

take the e^ of both side

e^0.0258 = (2412.06) / ( 0.0075V2^2 + 2313.9)

1.0261 = (2412.06) / ( 0.0075V2^2 + 2313.9)]

(0.0075V2^2 + 2313.9) = 2412.06 / 1.0261

(0.0075V2^2 + 2313.9) = 2350.7

0.0075V2^2 = 2350.7 - 2313.9

0.0075V2^2 = 36.8

V2^2 = 36.8 / 0.0075

V2^2 = 4906.6666

V2 = √4906.6666

V2 = 70.0476 ft/s

converting to miles per hour

V2 = 70.0476 ft/s * 1 mil / 5280 ft * 3600s / 1hr

V = 47.7 mi/hr

8 0
3 years ago
