iogann1982 [59]
3 years ago
12

Ear "popping" is an unpleasant phenomenon sometimes experienced when a change in pressure occurs, for example in a

Engineering
1 answer:
lara31 [8.8K]3 years ago
7 0

Answer:

a) dh_HG = 6.72 mm

b) dz' = 173 m @8000 m

Explanation:

Given:

Original height h_o = 3000 m

Descent = 100 m

Find:

what is the pressure change that your ears "pop" at, in millimeters of mercury?

If the airplane now rises to  8000 m and again begins descending, how far will the airplane descend before your ears "pop" again?

Solution:

- Assuming density of air remains constant from 3000 m to 2900 m. From Table A3:

                 p_air = 0.7423*p_SL = 0.7423*1.225 kg/m^3

                 p_air = 0.909 kg/m^3

- Manometer equation for air and mercury are as follows:

                dP = -p_air*g*descent                        dP = -p_HG*g*dh_HG

Combine the pressures dP:

               dh_HG = (p_air / p_HG)*descent

               dh_HG = 0.909*100 / 13.55*999

              dh_HG = 6.72 mm

- Assuming density of air remains constant from 8000 m to 7900 m. From Table A3:

                   p_air = 0.4292*p_SL = 0.4292*1.225 kg/m^3

                   p_air = 0.526 kg/m^3

- Manometer equation for air are as follows:

                       @8000m                                 @3000m

                dP = -p'_air*g*dz'                       dP = -p_air*g*dz



                                     dz' = p_air / p'_air * dz

                                     dz' = 0.909 / 0.526 * 100

                                     dz' = 173 m

You might be interested in
The voltage across a device and the current through it are:
butalik [34]

Answer:

attached below

Explanation:

3 0
3 years ago
Read 2 more answers
A solid cylindrical workpiece made of 304 stainless steel is 150 mm in diameter and 100 mm is high. It is reduced in height by 5
goblinko [34]

Answer:

45.3 MN

Explanation:

The forging force at the end of the stroke is given by

F = Y.π.r².[1 + (2μr/3h)]

The final height, h is given as h = 100/2

h = 50 mm

Next, we find the final radius by applying the volume constancy law

volumes before deformation = volumes after deformation

π * 75² * 2 * 100 = π * r² * 2 * 50

75² * 2 = r²

r² = 11250

r = √11250

r = 106 mm

E = In(100/50)

E = 0.69

From the graph flow, we find that Y = 1000 MPa, and thus, we apply the formula

F = Y.π.r².[1 + (2μr/3h)]

F = 1000 * 3.142 * 0.106² * [1 + (2 * 0.2 * 0.106/ 3 * 0.05)]

F = 35.3 * [1 + 0.2826]

F = 35.3 * 1.2826

F = 45.3 MN

7 0
3 years ago
An FPC 4 m2 in area is tested during the night to measure the overall heat loss coefficient. Water at 60 C circulates through th
sp2606 [1]

Answer:

<em> - 14.943 W/m^2K  ( negative sign indicates cooling ) </em>

Explanation:

Given data:

Area of FPC = 4 m^2

temp of water = 60°C

flow rate = 0.06 l/s

ambient temperature = 8°C

exit temperature = 49°C

<u>Calculate the overall heat loss coefficient </u>

Note : heat lost by water = heat loss through convection

m*Cp*dT  = h*A * ( T - To )

∴ dT / T - To = h*A / m*Cp  ( integrate the relation )

In ( \frac{49-8}{60-8} ) =  h* 4 / ( 0.06 * 10^-3 * 1000 * 4180 )

In ( 41 / 52 ) = 0.0159*h

hence h = - 0.2376 / 0.0159

              = - 14.943  W/m^2K  ( heat loss coefficient )

7 0
2 years ago
Argue the importance to society of incorporating green building into an engineer's designs, with at least two examples.
stellarik [79]

Answer:

Green Design is your answer

Explanation:

4 0
2 years ago
Read 2 more answers
Technician A says that mechanical shifting controls can wear out over time. Technician B says that vacuum control rubber diaphra
diamong [38]

Based on the information, both technician A and technician B are correct.

<h3>How to depict the information?</h3>

From the information given, Technician A says that mechanical shifting controls can wear out over time.

Technician B says that vacuum control rubber diaphragms can deteriorate over time.

In this case, both technicians are correct as the information depicted is true.

Learn more about technicians on:

brainly.com/question/1548867

#SPJ12

8 0
1 year ago
