This is a multi-part question. Once an answer is submitted, you will be unable to return to this part As steam is slowly injecte
1 answer:
You might be interested in
Answer:
The shear plane angle and shear strain are 28.21° and 2.155 respectively.
Explanation:
(a)
Orthogonal cutting is the cutting process in which cutting direction or cutting velocity is perpendicular to the cutting edge of the part surface.
Given:
Rake angle is 12°.
Chip thickness before cut is 0.32 mm.
Chip thickness is 0.65 mm.
Calculation:
Step1
Chip reduction ratio is calculated as follows:
r = 0.4923
Step2
Shear angle is calculated as follows:
Here, is shear plane angle, r is chip reduction ratio and
is rake angle.
Substitute all the values in the above equation as follows:
Thus, the shear plane angle is 28.21°.
(b)
Step3
Shears train is calculated as follows:
.
Thus, the shear strain rate is 2.155.
Answer:
Net discharge per hour will be 3.5325
Explanation:
We have given internal diameter d = 25 mm
Time = 1 hour = 3600 sec
So radius
We know that area is given by
We know that discharge is given by , here A is area and V is velocity
So
So net discharge in 1 hour =
