YALLL I NEED HELP ASAP... THIS DUE AT 11:59 AND ITS 10.42 RIGHT NOW

Two identical resistors are connected in parallel across a 26-V battery, which supplies them with a total power of 7.1 W. While

Gnom [1K]

Answer:

A) R = 190.42 Ω

B) P = 5.325 W

Explanation:

We are given;

Total power;P_tot = 7.1 W

Voltage;V = 26 V

A)We are told that while the battery is still connected, one of the resistors is heated, so that its resistance doubles.

Thus, the power is doubled.

Now, formula for power is;

P = IV

Thus, since power is doubled, we have;

P = 2(IV)

Now, formula for current is; I = V/R

So, P = 2V²/R

Making R the subject, we have;

R = 2V²/P

In this question, P is p_total = 7.1 W

Thus;

R = (2 × 26²)/7.1

R = 190.42 Ω

B) Now, the resistance of the resistors are R and 2R.

Formula for power in this context is;

P = V²/R

Thus,

Total power delivered to the resistors is;

P = V²/R + V²/2R

P = 3V²/2R

P = (3 × 26²)/(2 × 190.42)

P = 5.325 W

8 0

3 years ago

Which one of the following statements does not accurately describe vibrations?

Paladinen [302]

A. Forced vibrations, such as those between a tuning fork and a large cabinet surface, result in a much lower sound than was produced by the original vibrating body.

4 0

3 years ago

What's the frequency of a wave with a wavelength of 10 and velocity of 200m/s?

uranmaximum [27]

Answer:

$\boxed {\boxed {\sf 20 \ Hz}}$

Explanation:

The frequency of a wave can be found using the following formula.

$f=\frac{v}{\lambda}$

where f is the frequency, v is the velocity/wave speed, and λ is the wavelength.

The wavelength is 10 meters and the velocity is 200 meters per second.

1 m/s can also be written as 1 m*s^-1

Therefore:

$v= 200 \ m*s^{-1} \\\lambda = 10 \ m$

Substitute the values into the formula.

$f=\frac{200 \ m*s^{-1}}{10 \ m}$

Divide and note that the meters (m) will cancel each other out.

$f=\frac{200 \ s^{-1}}{10 \ }$

$f=20 \ s^{-1}$

1 s^-1 is equal to Hertz
Therefore, our answer of 20 s^-1 is equal to 20 Hz

$f= 20 \ Hz$

The frequency of the wave is 20 Hertz

7 0

2 years ago

According to the principle of faunal succession, what must be true of the fossils on a layer below? Now

Firdavs [7]

It means that they were set earlier therefor they are older.

7 0

3 years ago

Read 2 more answers

A box is sliding down a ramp how many force vectors does the box have

vlada-n [284]

Well you’d have a force due to gravity, the normal force which will be perpendicular to the sources (meaning you’ll have components to this vector), and you’d have the force of friction opposing the motion of the box. I’m also assuming there’s no air resistance. In this case you’d have three vector forces.

6 0

3 years ago
