3 years ago

Info security:

Engineering

1 answer:

il63 [147K]3 years ago

7 0

Answer:

True

Explanation:

Dual home host - it is referred to as the firewall that is incorporated with two or more networks. out of these two networks, one is assigned to the internal network and the other is for the network. The main purpose of the dual-homed host is to ensure that no Internet protocol traffic is induced between both the network.

The most simple example of a dual-homed host is a computing motherboard that is provided with two network interfaces.

You might be interested in

After the load impedance has been transformed through the ideal transformer, its impedance is: + . Enter the real part in the fi

frozen [14]

Answer:

Ig =7.2 +j9.599

Explanation: Check the attachment

6 0

2 years ago

25 In differential aeration corrosion, rich oxygenated parts are

sleet_krkn [62]

Answer:what are you trying to say

Explanation:

6 0

2 years ago

Air modeled as an ideal gas enters a turbine operating at steady state at 1040 K, 278 kPa and exits at 120 kPa. The mass flow ra

gladu [14]

Answer:

a) $T_{2}=837.2K$

b) $e=91.3$ %

Explanation:

A) First, let's write the energy balance:

$W=m*(h_{2}-h_{1})\\W=m*Cp*(T_{2}-T_{1})$ (The enthalpy of an ideal gas is just function of the temperature, not the pressure).

The Cp of air is: 1.004 $\frac{kJ}{kgK}$ And its specific R constant is 0.287 $\frac{kJ}{kgK}$ .

The only unknown from the energy balance is $T_{2}$ , so it is possible to calculate it. The power must be negative because the work is done by the fluid, so the energy is going out from it.

$T_{2}=T_{1}+\frac{W}{mCp}=1040K-\frac{1120kW}{5.5\frac{kg}{s}*1.004\frac{kJ}{kgk}} \\T_{2}=837.2K$

B) The isentropic efficiency (e) is defined as:

$e=\frac{h_{2}-h_{1}}{h_{2s}-h_{1}}$

Where ${h_{2s}$ is the isentropic enthalpy at the exit of the turbine for the isentropic process. The only missing in the last equation is that variable, because $h_{2}-h_{1}$ can be obtained from the energy balance $\frac{W}{m}=h_{2}-h_{1}$

$h_{2}-h_{1}=\frac{-1120kW}{5.5\frac{kg}{s}}=-203.64\frac{kJ}{kg}$

An entropy change for an ideal gas with constant Cp is given by:

$s_{2}-s_{1}=Cpln(\frac{T_{2}}{T_{1}})-Rln(\frac{P_{2}}{P_{1}})$

You can review its deduction on van Wylen 6 Edition, section 8.10.

For the isentropic process the equation is:

$0=Cpln(\frac{T_{2}}{T_{1}})-Rln(\frac{P_{2}}{P_{1}})\\Rln(\frac{P_{2}}{P_{1}})=Cpln(\frac{T_{2}}{T_{1}})$

Applying logarithm properties:

$ln((\frac{P_{2}}{P_{1}})^{R} )=ln((\frac{T_{2}}{T_{1}})^{Cp} )\\(\frac{P_{2}}{P_{1}})^{R}=(\frac{T_{2}}{T_{1}})^{Cp}\\(\frac{P_{2}}{P_{1}})^{R/Cp}=(\frac{T_{2}}{T_{1}})\\T_{2}=T_{1}(\frac{P_{2}}{P_{1}})^{R/Cp}$

Then,

$T_{2}=1040K(\frac{120kPa}{278kPa})^{0.287/1.004}=817.96K$

So, now it is possible to calculate $h_{2s}-h_{1}$ :

$h_{2s}-h_{1}}=Cp(T_{2s}-T_{1}})=1.004\frac{kJ}{kgK}*(817.96K-1040K)=-222.92\frac{kJ}{kg}$

Finally, the efficiency can be calculated:

$e=\frac{h_{2}-h_{1}}{h_{2s}-h_{1}}=\frac{-203.64\frac{kJ}{kg}}{-222.92\frac{kJ}{kg}}\\e=0.913=91.3$ %

4 0

3 years ago

2. What is the original length of the rectangular bar if the deformation is 0.005 in with a force of 1000 lbs and an area of 0.7

Ugo [173]

Answer:

18.75in

Explanation:

Modulus of elasticity = Stress/Strain

Since stress = Force/Area

Given

Force = 1000lb

Area = 0.75sqin

Stress = 1000/0.75

Stress = 1333.33lbsqin

Strain

Strain = Stress/Modulus of elasticity

Strain = 1333.33/5,000,000

Strain = 0.0002667

Also

Strain = extension/original length

extension = 0.005in

Original length = extension/strain

Original length = 0.005/0.0002667

Original length = 18.75in

Hence the original length of the rectangular bar is 18.75in

6 0

2 years ago

Charging method .Constant current method

mina [271]

Answer:

There are three common methods of charging a battery; constant voltage, constant current and a combination of constant voltage/constant current with or without a smart charging circuit.

Constant voltage allows the full current of the charger to flow into the battery until the power supply reaches its pre-set voltage. The current will then taper down to a minimum value once that voltage level is reached. The battery can be left connected to the charger until ready for use and will remain at that “float voltage”, trickle charging to compensate for normal battery self-discharge.

Constant current is a simple form of charging batteries, with the current level set at approximately 10% of the maximum battery rating. Charge times are relatively long with the disadvantage that the battery may overheat if it is over-charged, leading to premature battery replacement. This method is suitable for Ni-MH type of batteries. The battery must be disconnected, or a timer function used once charged.

Constant voltage / constant current (CVCC) is a combination of the above two methods. The charger limits the amount of current to a pre-set level until the battery reaches a pre-set voltage level. The current then reduces as the battery becomes fully charged. The lead acid battery uses the constant current constant voltage (CC/CV) charge method. A regulated current raises the terminal voltage until the upper charge voltage limit is reached, at which point the current drops due to saturation.

4 0
