HURRY PEASE what happens to current when there is a diode on the circuit and why?

Physics

1 answer:

kolbaska11 [484]3 years ago

6 0

Answer:

The current can't 'split down the parallel branch, because the diode is reverse biased so is blocking the flow of current. So basically it's acting as an open circuit. Also when the current flows it wouldn't reduce the currents amount flow through the resistor.

Explanation:
