Three 20.0 ohm resistors are

Physics

1 answer:

V125BC [204]2 years ago

5 0

Answer:

6.67 ohm

Explanation:

From the question given above, the following data were obtained:

Resistor 1 (R₁) =20 ohm

Resistor 2 (R₂) = 20 ohm

Resistor 3 (R₃) = 20 ohm

Equivalent Resistance (R) =?

Since the resistors are arranged in parallel connection, the equivalent resistance can be obtained as follow:

1/R = 1/R₁ + 1/R₂ + 1/R₃

1/R = 1/20 + 1/20 + 1/20

1/R = (1 + 1 + 1) / 20

1/R = 3/20

Invert

R = 20/3

R = 6.67 ohm

Therefore, the equivalent resistance is 6.67 ohm.
