Consider two points in an electric field. The potential at point 1, V1, is 33 V. The potential at point 2, V2, is 175 V. An elec

tron at rest at point 1 is accelerated by the electric field to point 2.
Required:
Write an equation for the change of electric potential energy ΔU of the electron in terms of the symbols given.
Physics
1 answer:
Mnenie [13.5K]2 years ago
5 0

Answer:

ΔU  = e(V₂ - V₁) and its value ΔU = -2.275 × 10⁻²¹ J

Explanation:

Since the electric potential at point 1 is V₁ = 33 V and the electric potential at point 2 is V₂ = 175 V, when the electron is accelerated from point 1 to point 2, there is a change in electric potential ΔV which is given by ΔV = V₂ - V₁.

Substituting the values of the variables into the equation, we have

ΔV = V₂ - V₁.

ΔV = 175 V - 33 V.

ΔV = 142 V

The change in electric potential energy ΔU = eΔV = e(V₂ - V₁) where e = electron charge = -1.602 × 10⁻¹⁹ C and ΔV = electric potential change from point 1 to point 2 = 142 V.

So, substituting the values of the variables into the equation, we have

ΔU = eΔV

ΔU = eΔV

ΔU = -1.602 × 10⁻¹⁹ C × 142 V

ΔU = -227.484 × 10⁻¹⁹ J

ΔU = -2.27484 × 10⁻²¹ J

ΔU ≅ -2.275 × 10⁻²¹ J

So, the required equation for the electric potential energy change is

ΔU  = e(V₂ - V₁) and its value ΔU = -2.275 × 10⁻²¹ J

You might be interested in
A 100 N force is applied to a box at an angle of 60° to the
Anarel [89]

Answer: lift force = 100sin60 = 86.6 N

             pull force = 100sin60 = 50.0 N

Explanation:

8 0
2 years ago
Physics - Electricity and Magnetism
Orlov [11]

Answer:

<h2>480</h2>

Explanation:

<h2>R=120÷0.25</h2><h2>R=480 ohms </h2>

because the unit for resistance is in ohms

4 0
2 years ago
Does anyone know these four?! I really need help and fast pls
Mama L [17]

Evidence: Data gathered

Experiment: Looking through a telescope

Observations: Testing what happens

Reasoning: Thinking a problem through

I believe that these should be correct.

Hoping you pass!

3 0
2 years ago
GIVING BRAINIEST TO FAST ANSWER!!!!
Vlad [161]

Answer:

The second one a part of it heats up Earth's land and water equally.

Explanation:

Hope this help!!!

4 0
2 years ago
Read 2 more answers
We can model a lightning bolt as a very long, straight wire. If a lightning bolt carries a current of 30 kA, and you are unfortu
Liula [17]

Answer:

Magnetic field experienced = 4.5 × 10⁻⁴ T

Explanation:

The magnetic field around an infinite straight current-carrying wire at a distance r from the wire is given by

B = (μ₀I)/(2πr)

B = ?

I = 20 KA = 20000 A

r = 8.9 m

μ₀ = magnetic permeability = 1.257 × 10⁻⁶ T.m/A

B = (1.257 × 10⁻⁶ × 20000)/(2π×8.9) = 4.5 × 10⁻⁴ T

8 0
3 years ago
