A space station consists of two donut-shaped living chambers, A and B, that have the radii shown in the drawing. As the station

rotates, an astronaut in chamber A is moved 2.30 102 m along a circular arc. How far along a circular arc is an astronaut in chamber B moved during the same time?

Physics
1 answer:
tensa zangetsu [6.8K]3 years ago
6 0
The angle subtended by the arc of movement of both chambers is the same. Thus:
S = r∅, for chamber A:

2.3 x 10² = 3.2 x 10² ∅
∅ = 0.72 rad

∅ is the same for B so:
S = 1.1 x 10³ x 0.72
S = 7.92 x 10² m
You might be interested in
In a manufacturing process, a large, cylindrical roller is used to flatten material fed beneath it. The diameter of the roller i
kotykmax [81]

The maximum angular speed of the roller is 3.47rad/a,

the maximum tangential speed of the point an the rim of the roller is 1.47m/s,

the time t should the driven force be removed from the roller so that the roller does not reverse its direction of rotation is t = 2.78s,

5.4 rotation has the roller turned between t=0 and the time found in part c

<h3>What does tangential speed refer to?</h3>

Any item moving along a circular path has a linear component to its speed called tangential velocity. An object's velocity is always pointed tangentially when it travels in a circle at a distance r from the center. The word for this is tangential velocity.

To calculate the tangential speed, divide the circumference by the time required to complete one spin. For instance, if it takes 12 seconds to complete one rotation, divide 18.84 by 12 to get 1.57 feet per second as the tangential velocity.

(a) angular speed w = dθ/dt = 5t - 1.8t^2

dw/dt = 5 - 3.6t = 0 for max w

so max w occurs at t = 5/3.6 s = 1.39s

so w max = 5*1.39 - 1.8*(1.39)^2 = 3.47 rad/s

(b) tangential speed v = r*w

r = D/2 = 0.5m

so v = 0.5*w = 1.74 m/s

(c) w is positive until 5t = 1.8t^2

so t = 5/1.8s = 2.78s (or t = 0 invalid)

After t = 2.87s, w is negative (starts reversing direction of rotation)

Driving force would actually have to be removed some time before t=2.78s because the roller can't stop instantaneously, but insufficient info to calculate this.

(d) Up to t = 2.78s, θ = 2.5*(2.78)^2 - 0.6*(2.78)^3 rad = 33.95 rad = 5.40 rotations

Therefore,

A) 3.47rad/a

B) 1.47m/s

C) t = 2.78s

D) 5.4 rotation

To learn more about tangential speed, refer to:

brainly.com/question/19660334

#SPJ4

4 0
1 year ago
My question is An object may be acted on by several forces. What name is given to the single force that has the same effect as t
wariber [46]
Newtons Law of motion
6 0
3 years ago
Read 2 more answers
Which of the following best describes the use of a renewable resource? (2 points) Most power plants burn fossil fuels to generat
kolbaska11 [484]

Which of the following best describes the use of a renewable resource?

Answer:

There are areas in California that use the heat from deep in the Earth to generate electricity.

Explanation:

It comes from the earth itself and we use a lot of things that comes from the earth and deep within it.

5 0
3 years ago
When a 2.50 kg object is hung vertically on a certain light spring described by hookes law the spring stretches 2.76 cm.
Readme [11.4K]
F=K*X,
F=M*a

M*a=K*X

2.5*9.81=K*0.0276

24.525=K*0.0276

24.525/0.0276=K

K= 888.6 N/m ---- force constant

assuming 2.5 refers to the new extension, just divide F/ 0.025
to get

981N/m


8 0
3 years ago
If your parents were going through a divorce and you needed to talk to someone, who would be the best professional to see?Clinic
just olya [345]

psychologist counseling would be the correct answer I believe

3 0
3 years ago
Read 2 more answers
