A wire of length 26.0 cm carrying a current of 5.77 mA is to be formed into a circular coil and placed in a uniform magnetic fie

ld B of magnitude 3.67 mT. If the torque on the coil from the field is maximized, what is the magnitude of that maximum torque
Physics
1 answer:
Olin [163]3 years ago
7 0

Answer:

The maximum torque is  \tau_{max} =  1.139 *10^{-7} \ N \cdot m

Explanation:

From the question we are told that

   The length of the wire is  l =  26.0 \ cm  =  0.26 \  m

     The current flowing through the wire is  I  = 5.77mA  =  5.77 *10^{-3} \ A

      The magnetic field is  B = 3.67 \ mT  =  3.67 *10^{-3 } T



The maximum torque is mathematically evaluated as

        \tau_{max} =   \mu B

Where \mu  is the magnetic dipole moment which is mathematically represented as

        \mu  =  \frac{I l^2}{4 \pi n }

Where n is the number of turns which from the question is  1

    substituting values

       \mu  =  \frac{ 5.77 *10^{-3}  *  0.26^2}{4  * 3.142* 1 }

     \mu  =  3.10 4*  10^{-5}  A m^2

Now

      \tau_{max} =  3.104 *10^{-5} * 3.67 *10^{-3}

      \tau_{max} =  1.139 *10^{-7} \ N \cdot m
