3 years ago

I WILL GIVE 20 POINTS!!

Engineering

2 answers:

Ludmilka [50]3 years ago

6 0

Use a resume header

Alex777 [14]3 years ago

5 0

Answer:

Use a resume header

Explanation:

Create a Summary

Research industry, employer keywords

there are some hints okay

You might be interested in

An Ideal gas is being heated in a circular duct as while flowing over an electric heater of 130 kW. The diameter of duct is 500

Assoli18 [71]

Answer: The exit temperature of the gas in deg C is $32^{o}C$ .

Explanation:

The given data is as follows.

$C_{p}$ = 1000 J/kg K, R = 500 J/kg K = 0.5 kJ/kg K (as 1 kJ = 1000 J)

$P_{1}$ = 100 kPa, $V_{1} = 15 m^{3}/s$

$T_{1} = 27^{o}C = (27 + 273) K = 300 K$

We know that for an ideal gas the mass flow rate will be calculated as follows.

$P_{1}V_{1} = mRT_{1}$

or, m = $\frac{P_{1}V_{1}}{RT_{1}}$

= $\frac{100 \times 15}{0.5 \times 300}$

= 10 kg/s

Now, according to the steady flow energy equation:

$mh_{1} + Q = mh_{2} + W$

$h_{1} + \frac{Q}{m} = h_{2} + \frac{W}{m}$

$C_{p}T_{1} - \frac{80}{10} = C_{p}T_{2} - \frac{130}{10}$

$(T_{2} - T_{1})C_{p} = \frac{130 - 80}{10}$

$(T_{2} - T_{1})$ = 5 K

$T_{2}$ = 5 K + 300 K

$T_{2}$ = 305 K

= (305 K - 273 K)

= $32^{o}C$

Therefore, we can conclude that the exit temperature of the gas in deg C is $32^{o}C$ .

8 0

3 years ago

The advantage of using rose bud tips is that they:

Jlenok [28]

Answer:

The advantage to using a rosebud tip is that it expands the flame temperature over a wider area vs using a #0 size tip.

Explanation:

Hope this helped Mark BRAINLIEST!!

3 0

2 years ago

A shunt regulator utilizing a zener diode with an incremental resistance of 8 ohm is fed through an 82-Ohm resistor. If the raw

spayn [35]

Answer:

$\triangle V_0=0.08V$

Explanation:

From the question we are told that:

Incremental resistance $R=8ohms$

Resistor Feed $R_f=82ohms$

Supply Change $\triangle V=1$

Generally the equation for voltage rate of change is mathematically given by

$\frac{dV_0}{dV}=\frca{R}{R_1r_3}$

Therefore

$\triangle V_0=\triangle V*\frac{R}{R_fR}$

$\triangle V_0=1*\frac{8}{8*82}$

$\triangle V_0=0.08V$

7 0

3 years ago

When your fixing a car, what is the first thing you want to do?

Shtirlitz [24]

Answer:

Changing oil.

Explanation:

You need to regularly check and change your car’s oil to ensure smooth running of the vehicle and to prolong the lifespan of its engine.

6 0

2 years ago

A sign erected on uneven ground is guyed by cables EF and EG. If the force exerted by cable EF at E is 46 lb, determine the mome

Vikki [24]

Answer:

M_AD = 1359.17 lb-in

Explanation:

Given:

- T_ef = 46 lb

Find:

- Moment of that force T_ef about the line joining points A and D.

Solution:

- Find the position of point E:

mag(BC) = sqrt ( 48^2 + 36^2) = 60 in

BE / BC = 45 / 60 = 0.75

Hence, E = < 0.75*48 , 96 , 36*0.75> = < 36 , 96 , 27 > in

- Find unit vector EF:

mag(EF) = sqrt ( (21-36)^2 + (96+14)^2 + (57-27)^2 ) = 115 in

vec(EF) = < -15 , -110 , 30 >

unit(EF) = (1/115) * < -15 , -110 , 30 >

- Tension T_EF = (46/115) * < -15 , -110 , 30 > = < -6 , -44 , 12 > lb

- Find unit vector AD:

mag(AD) = sqrt ( (48)^2 + (-12)^2 + (36)^2 ) = 12*sqrt(26) in

vec(AD) = < 48 , -12 , 36 >

unit(AD) = (1/12*sqrt(26)) * < 48 , -12 , 36 >

unit (AD) = <0.7845 , -0.19612 , 0.58835 >

M_AD = unit(AD) . ( E x T_EF)

$M_d = \left[\begin{array}{ccc}0.7845&-0.19612&0.58835\\36&96&27\\-6&-44&12\end{array}\right]$

M_AD = 1835.73 + 116.49528 - 593.0568

M_AD = 1359.17 lb-in

3 0

3 years ago
