Question

The conductive tissues of the upper leg can be modeled as a 40-cm-long, 12-cm-diameter cylinder of muscle and fat. The resistivities of muscle and fat are 13 Ω m and 25 Ω m, respectively. One person’s upper leg is 82% muscle, 18% fat. What current is measured if a 1.5 V potential difference is applied between the person’s hip and knee?

Answer 1

To calculate and solve the problem it is necessary to apply the concepts related to resistance and resistivity.

The equation that is responsible for relating the two variables is:

$R = \rho \frac{L}{A}$

Where,

R= Resistance of the conductor

$\rho =$Resistivity of the conductor material

L = Length

A = Cross-sectional area of conductor

With the previous values the area of the muscle (Real Muscle-82%)is,

$A_m = (0.82)\pi r^2 = (0.82)\pi (12/2*10^{-2})^2$

$A_m = 9.274*10^{-3}m^2$

Using the equation from Resistance we have that at the muscle the value is:

$R_m = \rho \frac{L}{A}$

$R_m = \frac{13*(0.4)}{9.274*10^{-3}}$

$R_m = 560.70\Omega$

At the same time we can make the same process to calculate the resistance of the fat, then

$A_m = (0.18)\pi r^2 = (0.18)\pi (12/2*10^{-2})^2$

$A_m = 2.0357*10^{-3}m^2$

The resistance of the fat would be,

$R_f = \rho \frac{L}{A}$

$R_f = \frac{25*(0.4)}{2.0357*10^{-3}}$

$R_f = 4912.3\Omega$

Then the total resistance in a set as the previously writen, i.e, in parallel is:

$R=\frac{R_mR_f}{R_m+R_f}$

$R = \frac{(560.70)(4912.3)}{4912.3+560.70}$

$R = 502.62\Omega$

We can here apply Ohm's law, then

$I= \frac{V}{R}$

$I = \frac{1.5}{502.62}$

$I = 2.984*10^{-3}A$

$I = 2.984mA$
