Answer:
a) 229.4281 hp.
b) 262.15 ft3/min.
Explanation:
Given data:
P1 = 14.2 psi
T1 = 60°F = 520° R
P2 = 120 psi
T2 = 500°F = 960° R
volumetric flow rate ( Av1 ) = 1200 ft^3 /min = 20 ft^3 / sec
attached below is the detailed solution
Answer:
D.
Explanation:
In automated welding, defined as “welding with equipment that requires only occasional or no observation of the weld, and no manual adjustment of the equipment controls,” the welder's involvement is limited to activating the machine to initiate the welding cycle and observing the weld on an intermittent basis.
Answer:
Here are 2 sense i cant find 4
Explanation:
Levers are used to multiply force, In other words, using a lever gives you greater force or power than the effort you put in.
In a lever, if the distance from the effort to the fulcrum is longer than the distance from the load to the fulcrum, this gives a greater mechanical advantage.
Answer:
Gc(s) =
Explanation:
comparing the standard approximation with the plot attached we can tune the PI gains so that the desired response is obtained. this is because the time requirement of the setting is met while the %OS requirement is not achieved instead a 12% OS is seen from the plot.
attached is the detailed solution and the plot in Matlab
Answer:
a) A suspended floor is a ground floor with a void underneath the structure. The floor can be formed in various ways, using timber joists, precast concrete panels, block and beam system or cast in-situ with reinforced concrete. However, the floor structure is supported by external and internal walls.
b) Soil exploration consists of determining the profile of the natural soil deposits at the site, taking the soil samples and determining the engineering properties of soils using laboratory tests as well as in-situ testing methods
c) Bulking in sand Occurs When dry sand interacts with the atmospheric moisture. Presence of moisture content forms a thin layer around sand particles. This layer generates the force which makes particles to move aside to each other. This results in the increase of the volume of sand.
d) In a nutshell, bearing capacity is the capacity of soil to support the loads that are applied to the ground above. It depends primarily on the type of soil, its shear strength and its density. It also depends on the depth of embedment of the load – the deeper it is founded, the greater the bearing capacity.
Explanation:
