What is a magnetic field’s shape?

Physics

1 answer:

Agata [3.3K]3 years ago

7 0

Answer:

Magnets come in a variety of shapes and one of the more common is the horseshoe (U) magnet. The horseshoe magnet has north and south poles just like a bar magnet but the magnet is curved so the poles lie in the same plane. The magnetic lines of force flow from pole to pole just like in the bar magnet.

You might be interested in

A straight wire 20 cm long, carrying a current of 4 A, is in a uniform magnetic field of 0.6 T. What is the force on the wire wh

zheka24 [161]

Answer:

Magnetic force, F = 0.24 N

Explanation:

It is given that,

Current flowing in the wire, I = 4 A

Length of the wire, L = 20 cm = 0.2 m

Magnetic field, B = 0.6 T

Angle between force and the magnetic field, θ = 30°. The magnetic force is given by :

$F=ILB\ sin\theta$

$F=4\ A\times 0.2\ m\times 0.6\ T\ sin(30)$

F = 0.24 N

So, the force on the wire at an angle of 30° with respect to the field is 0.24 N. Hence, this is the required solution.

7 0

4 years ago

Read 2 more answers

Hans Selye’s general adaptation syndrome theory proposes that adaptation to stress occurs in how many stages?

ANTONII [103]

Answer:

Adaption to stress occurs in three stages: alarm, fight or flight, exhaustion.

Explanation:

According to the general adaptation syndrome theory proposed by Hans Selye, the adaption to stress occurs in three stages which are:

1. alarm

2. fight or flight

3. exhaustion

This is a process which comprises of three stages that describes the physiological changes which a body undergoes when in stress (an emotional, mental and physical human response to a specific stimulus).

4 0

3 years ago

What was one main point of Dalton's atomic theory

goblinko [34]

All matter is composed of atoms, indestructible building blocks.

4 0

4 years ago

Read 2 more answers

Suppose a straight 1.00-mm-diameter copper wire could just "float" horizontally in air because of the force due to the Earth’s m

insens350 [35]

To solve this problem it is necessary to apply the concepts related to the Force since Newton's second law, as well as the concept of Electromagnetic Force. The relationship of the two equations will allow us to find the magnetic field through the geometric relations of density and volume.

$F_{mag}= BIL$

Where,

B = Magnetic Field

I = Current

L = Length

Note: $F_{mag}$ is a direct adaptation of the vector relation $F=q \times V \times B$

From Newton's second law we know that the relation of Strength and weight is determined as

$F_g = mg$

Where,

m = Mass

g = Gravitational Acceleration

For there to be balance the two forces must be equal therefore

$F_{mag} = F_g$

$BIL = mg$

Our values are given as,

Diameter $(d) = 1.0mm = 1*10^{-3}m$

Radius $(r) = \frac{d}{2} = \frac{1*10^{-3}}{2} = 0.5*10^{-3}m$

Magnetic Field $(B) = 5.0*10^{-5} T$

From the relationship of density another way of expressing mass would be

$\rho = \frac{m}{V} \rightarrow m = \rho V$

At the same time the volume ratio for a cylinder (the shape of the wire) would be

$V = \pi r^2 L \rightarrow L =Length, r= Radius$

Replacing this two expression at our first equation we have that:

$BIL = mg$

$BIL = ( \rho V)g$

$BIL = ( \rho \pi r^2 L)g$

Re-arrange to find I

$I = \frac{( \rho \pi r^2 L)g}{BL}$

$I = \frac{( \rho \pi r^2 )g}{B}$

We have for definition that the Density of copper is $8.9*10^3 Kg/m^3$ , gravity acceleration is $9.8m/s^2$ and the values of magnetic field (B) and the radius were previously given, then:

$I = \frac{( (8.9*10^3 ) \pi (0.5*10^{-3})^2 )(9.8)}{5.0*10^{-5}}$

$I = 1370.05A$

The current is too high to be transported which would make the case not feasible.

8 0

3 years ago

Which pair of atoms forms ionic bonds?

natta225 [31]

Mental and non mental, an ionic bond is a type of chemical bond formed through an electrostatic attraction between two oppositely charged ions. Ionic bonds are formed between a cation, which is usually a metal, and an anion, which is usually a nonmetal.
