Answer:
Bridge
Explanation:
A common, simply bridge truss is the zigzag.
Answer:
Plan symbols /Architectural symbols
Explanation:
A blueprint drawing is a drawing used in the building and construction industry to show engineers and contractors how a building, an object or a system is to be constructed and implemented including final finishing. Graphical symbols are used in these diagrams to refer readers of the drawing to other drawings in the blueprint set. Symbols make it simple for experts that prepare the drawings and further help to ensure the file document is acceptable in size.
Answer:
And Im still going with B..
Answer:
I. 3.316 kW
II. 1.218 kW
III. 2.72
Explanation:
At state 1, the enthalpy and entropy are determined using the given data from A-13.
At P1 = 200kpa and T1 = 0,
h1 = 253.07 kJ/kg
s1 = 0.9699 kJ/kgK
At state 2, the isentropic enthalpy is determined at P2 = 1400kpa and s1 = s2 by interpolation. Thus
h2(s) = 295.95 kJ/kg
The actual enthalpy is then gotten by
h2 = h1 + [h2(s) - h1]/n
h2 = 253.07 + [295.95 - 253.07]/0.88
h2 = 253.07 + 48.73
h2 = 301.8 kJ/kg
h3 = h4 = 120.43 kJ/kg
Heating load is determined from energy balance, thus,
Q'l = m'(h1 - h4)
Q'l = 0.025(253.07 - 120.43)
Q'l = 0.025 * 132.64
Q'l = 3.316 kW
Power is determined by using
W' = m'(h2 - h1)
W'= 0.025(301.8 - 253.07)
W'= 0.025 * 48.73
W'= 1.218 kW
The Coefficient Of Performance is Q'l / W'
COP = 3.316/1.218
COP = 2.72
