Answer:
efficiency =42.62%
AMOUNT OF POWER REJECTED IS 20.080 kW
Explanation:
given data:
power 20 hp
heat energy = 35kW
power production = 20 hp = 20* 746 W = 14920 Watt [1 hp =746 watt]



=42.62%
b)

= 20.080 kW
AMOUNT OF POWER REJECTED IS 20.080 kW
Answer:
<em>181 °C</em>
<em></em>
Explanation:
Initial pressure
= 100 kPa
Initial temperature
= 30 °C = 30 + 273 K = 303 K
Final pressure
= 1200 kPa
Final temperature
= ?
n = 1.2
For a polytropic process, we use the relationship
(
/
) = (
/
)^γ
where γ = (n-1)/n
γ = (1.2-1)/1.2 = 0.1667
substituting into the equation, we have
(
/303) = (1200/100)^0.1667
/303 = 12^0.1667
/303 = 1.513
= 300 x 1.513 = 453.9 K
==> 453.9 - 273 = 180.9 ≅ <em>181 °C</em>
Answer:
R = 148.346 N
M₀ = - 237.2792 N-m
Explanation:
Point O is selected as a convenient reference point for the force-couple system which is to represent the given system
We can apply
∑Fx = Rx = - 60N*Cos 45° + 40N + 80*Cos 30° = 66.8556 N
∑Fy = Ry = 60N*Sin 45° + 50N + 80*Sin 30° = 132.4264 N
Then
R = √(Rx²+Ry²) ⇒ R = √((66.8556 N)²+(132.4264 N)²)
⇒ R = 148.346 N
Now, we obtain the moment about the origin as follows
M₀ = (0 m*40 N)-(7 m*60 N*Sin 45°)+(4 m*60 N*Cos 45°)-(5 m*50 N)+ 140 N-m + (0 m*80 N*Cos 30°) + (0 m*80 N*Sin 30°) = - 237.2792 N-m (clockwise)
We can see the pic shown in order to understand the question.
