A plate clutch is used to connect a motor shaft running at 1500rpm to shaft 1. The motor is rated at 4 hp. Using a service facto

vazorg [7]

Answer:

$(M_t)_{rated}=61.11lb-in$

Explanation:

speed of motor (N)=1500 rpm

power=4 hp = $4 \times 0.7457$ =2.9828 KW

service factor(k)= 2.75

now,

$KW=\frac{2\pi n M_t}{60 \times 10^6} \\2.9828=\frac{2\pi \times 1500 M_t}{60 \times 10^6}\\M_t=\frac{2.9828\times 60 \times 10^6}{2\pi \times 1500 }$

$M_t= 18,989.09 \ N-mm= 168.06 lb-in$

torque rating

$(M_t)_{design}=k_s\times (M_t)_{rated}\\168.06= 2.75\times (M_t)_{rated}\\(M_t)_{rated}=\frac{168.06}{2.75} \\(M_t)_{rated}=61.11lb-in$

4 0

3 years ago

How do you extablish a chain of dimensions

kap26 [50]

Answer:

Certamente você conhece três dimensões: comprimento, largura e profundidade. Além disso, quando se pensa um pouco fora da caixa também seria possível adicionar a dimensão do tempo.

Provavelmente, algumas pessoas viajam na maionese quando toca-se nesse assunto. Vem em suas mentes universos paralelos e até mesmo realidades alternativas. Mas também não se trata disso.

Explanation:

Basicamente as dimensões são as facetas do que nós percebemos a ser realidade. Existem muitos debates sobre dimensões na física. Um dos que mais chamam a atenção se chama Teoria das Cordas.

r

5 0

2 years ago

The ???? − i relationship for an electromagnetic system is given by ???? = 1.2i1/2 g where g is the air-gap length. For current

Artemon [7]

Answer:

a) The mechanical force is -226.2 N

b) Using the coenergy the mechanical force is -226.2 N

Explanation:

a) Energy of the system:

$\lambda =\frac{1.2*i^{1/2} }{g} \\i=(\frac{\lambda g}{1.2} )^{2}$

$\frac{\delta w_{f} }{\delta g} =\frac{g^{2}\lambda ^{3} }{3*1.2^{2} }$

$f_{m}=- \frac{\delta w_{f} }{\delta g} =-\frac{g^{2}\lambda ^{3} }{3*1.2^{2} }$

If i = 2A and g = 10 cm

$\lambda =\frac{1.2*i^{1/2} }{g} =\frac{1.2*2^{1/2} }{10x10^{-2} } =16.97$

$f_{m}=-\frac{g^{2}\lambda ^{3} }{3*1.2^{2} }=-\frac{16.97^{3}*2*0.1 }{3*1.2^{2} } =-226.2N$

b) Using the coenergy of the system:

$f_{m}=- \frac{\delta w_{f} }{\delta g} =-\frac{1.2*2*i^{3/2} }{3*g^{2} }=-\frac{1.2*2*2^{3/2} }{3*0.1^{2} } =-226.2N$

8 0

2 years ago

Can someone draw a electric circuit with electrical symbols for this

erastovalidia [21]

Answer:

i cant draw it

i am sry

Explanation:

4 0

2 years ago

Read 2 more answers

You are about to perform PMCS on your M1114? What resource should you use for the procedures and instructions for performing PMC

aniked [119]

The resources and instructions that should be used for the procedures of performing PMCS are:

Operator's manuals
Safety cautions and warnings.
Fording kit
Heating and cooling systems.

PMCS is an acronym for preventive maintenance checks and services and it can be defined as the maintenance, checks, and services that are typically performed before, during, and after the use of any type of military equipment such as:

M1114

M1151

M1123

Basically, the resources and instructions that should be used for the procedures of performing PMCS are:

Operator's manuals
Safety cautions and warnings.
Fording kit
Heating and cooling systems.

Read more on PMCS here: brainly.com/question/15720250

#SPJ1

4 0

1 year ago
