Air at 293k and 1atm flow over a flat plate at 5m/s. The plate is 5m wide and 6m long. (a) Determine the boundary layer thicknes

loris [4]

Answer:

a). 8.67 x $10^{-3}$ m

b).0.3011 m

c).0.0719 m

d).0.2137 N

e).1.792 N

Explanation:

Given :

Temperature of air, T = 293 K

Air Velocity, U = 5 m/s

Length of the plate is L = 6 m

Width of the plate is b = 5 m

Therefore Dynamic viscosity of air at temperature 293 K is, μ = 1.822 X $10^{-5}$ Pa-s

We know density of air is ρ = 1.21 kg / $m^{3}$

Now we can find the Reyonld no at x = 1 m from the leading edge

Re = $\frac{\rho .U.x}{\mu }$

Re = $\frac{1.21 \times 5\times 1}{1.822\times 10^{-5} }$

Re = 332052.6

Therefore the flow is laminar.

Hence boundary layer thickness is

δ = $\frac{5.x}{\sqrt{Re}}$

= $\frac{5\times 1}{\sqrt{332052.6}}$

= 8.67 x $10^{-3}$ m

a). Boundary layer thickness at x = 1 is δ = 8.67 X $10^{-3}$ m

b). Given Re = 100000

Therefore the critical distance from the leading edge can be found by,

Re = $\frac{\rho .U.x}{\mu }$

100000 = $\frac{1.21\times5\times x}{1.822 \times10^{-5}}$

x = 0.3011 m

c). Given x = 3 m from the leading edge

The Reyonld no at x = 3 m from the leading edge

Re = $\frac{\rho .U.x}{\mu }$

Re = $\frac{1.21 \times 5\times 3}{1.822\times 10^{-5} }$

Re = 996158.06

Therefore the flow is turbulent.

Therefore for a turbulent flow, boundary layer thickness is

δ = $\frac{0.38\times x}{Re^{\frac{1}{5}}}$

= $\frac{0.38\times 3}{996158.06^{\frac{1}{5}}}$

= 0.0719 m

d). Distance from the leading edge upto which the flow will be laminar,

Re = $\frac{\rho \times U\times x}{\mu }$

5 X $10^{5}$ = $\frac{1.21 \times 5\times x}{1.822\times 10^{-5}}}$

x = 1.505 m

We know that the force acting on the plate is

$F_{D}$ = $\frac{1}{2}\times C_{D}\times \rho \times A\times U^{2}$

and $C_{D}$ at x= 1.505 for a laminar flow is = $\frac{1.328}{\sqrt{Re}}$

= $\frac{1.328}{\sqrt{5\times10 ^{5}}}$

= 1.878 x $10^{-3}$

Therefore, $F_{D}$ = $\frac{1}{2}\times C_{D}\times \rho \times A\times U^{2}$

= $\frac{1}{2}\times 1.878\times 10^{-3}\times 1.21\times (5\times 1.505)\times 5^{2}$

= 0.2137 N

e). The flow is turbulent at the end of the plate.

Re = $\frac{\rho \times U\times x}{\mu }$

= $\frac{1.21 \times 5\times 6}{1.822\times 10^{-5} }$

= 1992316

Therefore $C_{D}$ = $\frac{0.072}{Re^{\frac{1}{5}}}$

= $\frac{0.072}{1992316^{\frac{1}{5}}}$

= 3.95 x $10^{-3}$

Therefore $F_{D}$ = $\frac{1}{2}\times C_{D}\times \rho\times A\times U^{2}$

= $\frac{1}{2}\times 3.95\times 10^{-3}\times 1.21\times (5\times 6)\times 5^{2}$

= 1.792 N

3 0

3 years ago

Refrigerant 134a enters an air conditioner compressor at 4 bar, 20 C, and is compressed at steady state to 12 bar, 80 C. The vol

sleet_krkn [62]

Answer:

$Q=15.7Kw$

Explanation:

From the question we are told that:

Initial Pressure $P_1=4bar$

Initial Temperature $T_1=20 C$

Final Pressure $P_2=12 bar$

Final Temperature $T_2=80C$

Work Output $W= 60 kJ/kg$

Generally Specific Energy from table is

At initial state

$P_1=4bar \& T_1=20 C$

$E_1=262.96KJ/Kg$

With

Specific Volume $V'=0.05397m^3/kg$

At Final state

$P_2=12 bar \& P_2=80C$

$E_1=310.24KJ/Kg$

Generally the equation for The Process is mathematically given by

$m_1E_1+w=m_2E_2+Q$

Assuming Mass to be Equal

$m_1=m_1$

Where

$m=\frac{V}{V'}$

$m=frac{0.06666}{V'=0.05397m^3/kg}$

$m=1.24$

Therefore

$1.24*262.96+60)=1.24*310.24+Q$

$Q=15.7Kw$

4 0

3 years ago

A(n) ______ is used to measure fluid flow in engineering

Arte-miy333 [17]

Answer:

A pitot tube is used to measure fluid flow in engineering

3 0

2 years ago

A storage tank, used in a fermentation process, is to be rotationally molded from polyethylene plastic. This tank will have a co

NNADVOKAT [17]

Answer:

The volume up to cylindrical portion is approx 32355 liters.

Explanation:

The tank is shown in the attached figure below

The volume of the whole tank is is sum of the following volumes

1) Hemisphere top

Volume of hemispherical top of radius 'r' is

$V_{hem}=\frac{2}{3}\pi r^3$

2) Cylindrical Middle section

Volume of cylindrical middle portion of radius 'r' and height 'h'

$V_{cyl}=\pi r^2\cdot h$

3) Conical bottom

Volume of conical bottom of radius'r' and angle $\theta$ is

$V_{cone}=\frac{1}{3}\pi r^3\times \frac{1}{tan(\frac{\theta }{2})}$

Applying the given values we obtain the volume of the container up to cylinder is

$V=\pi 1.5^2\times 4.0+\frac{1}{3}\times \frac{\pi 1.5^{3}}{tan30}=32.355m^{3}$

Hence the capacity in liters is $V=32.355\times 1000=32355Liters$
