Answer: the correct answer is D
The controller determines if a(n) error exists by calculating the difference between the SP and the PV.
<h3>How does a
controller work in control system?</h3>
The Control system is one where it entails if the output is one that has an effect on the input quantity.
So it uses the PV(Process Variable) set against the SP(Setpoint) to know if an error exists.
So, The controller determines if a(n) error exists by calculating the difference between the SP and the PV.
Learn more about controller from
brainly.com/question/14617664
#SPJ1
Answer:
••• like a story pole but has information for only one portion of the wall. system. methods and materials of construction.
Answer:
The maximum power that can be generated is 127.788 kW
Explanation:
Using the steam table
Enthalpy at 20 bar = 2799 kJ/kg
Enthalpy at 2 bar = 2707 kJ/kg
Change in enthalpy = 2799 - 2707 = 92 kJ/kg
Mass flow rate of steam = 5000 kg/hr = 5000 kJ/hr × 1 hr/3600 s = 1.389 kg/s
Maximum power generated = change in enthalpy × mass flow rate = 92 kJ/kg × 1.389 kg/s = 127.788 kJ/s = 127.788 kW
It’s in Wolfsburg Germany
