What stands for sound navigation and ranging

1 answer:

6 0

Sonar, originally an <span>acronym for SOund Navigation And Ranging
</span>a technique that uses sound<span> propagation.</span>

You might be interested in

Can someone slove these problems please with work step by step :(

Rudik [331]

Answer:

i like how your computer thing is red, mine is orange bc i have a haikyuu wallpaper

Explanation:

6 0

3 years ago

A capacitor is formed from two concentric spherical conducting shells separated by vacuum. The inner sphere has radius 11.0 cm ,

viktelen [127]

Part A)
First of all, let's convert the radii of the inner and the outer sphere:
$r_A = 11.0 cm = 0.110 m$
$r_B = 16.5 cm=0.165 m$
The capacitance of a spherical capacitor which consist of two shells with radius rA and rB is
$C=4 \pi \epsilon _0 \frac{r_A r_B}{r_B- r_A}=4\pi(8.85 \cdot 10^{-12}C^2m^{-2}N^{-1}) \frac{(0.110m)(0.165m)}{0.165m-0.110m}=$
$=3.67\cdot 10^{-11}F$

Then, from the usual relationship between capacitance and voltage, we can find the charge Q on each sphere of the capacitor:
$Q=CV=(3.67\cdot 10^{-11}F)(100 V)=3.67\cdot 10^{-9}C$

Now, we can find the electric field at any point r located between the two spheres, by using Gauss theorem:
$E\cdot (4 \pi r^2) = \frac{Q}{\epsilon _0}$
from which
$E(r) = \frac{Q}{4 \pi \epsilon_0 r^2}$
In part A of the problem, we want to find the electric field at r=11.1 cm=0.111 m. Substituting this number into the previous formula, we get
$E(0.111m)=2680 N/C$

And so, the energy density at r=0.111 m is
$U= \frac{1}{2} \epsilon _0 E^2 = \frac{1}{2} (8.85\cdot 10^{-12}C^2m^{-2}N^{-1})(2680 N/C)^2=3.17 \cdot 10^{-5}J/m^3$

Part B) The solution of this part is the same as part A), since we already know the charge of the capacitor: $Q=3.67 \cdot 10^{-9}C$ . We just need to calculate the electric field E at a different value of r: r=16.4 cm=0.164 m, so
$E(0.164 m)= \frac{Q}{4 \pi \epsilon_0 r^2}=1228 N/C$

And therefore, the energy density at this distance from the center is
$U= \frac{1}{2}\epsilon_0 E^2 = \frac{1}{2} (8.85\cdot 10^{-12}C^2m^{-2}N^{-1})(1228 N/C)^2=6.68 \cdot 10^{-6}J/m^3$

8 0

3 years ago

Obi Wan uses his Jedi mind tricks to compel people to do his will. The words he uses begin in his vocal cords which _____ the ai

lutik1710 [3]

I believe it is vibrate

7 0

3 years ago

Read 2 more answers

Which organization functions to privide clinics and surgeries i developing nations

Nimfa-mama [501]

Doctors without boarders.

4 0

3 years ago

Can anyone solve these for my by using unit vectors? Can you also please show your work

Oxana [17]

4. The Coyote has an initial position vector of $\vec r_0=(15.5\,\mathrm m)\,\vec\jmath$ .

4a. The Coyote has an initial velocity vector of $\vec v_0=\left(3.5\,\frac{\mathrm m}{\mathrm s}\right)\,\vec\imath$ . His position at time $t$ is given by the vector

$\vec r=\vec r_0+\vec v_0t+\dfrac12\vec at^2$

where $\vec a$ is the Coyote's acceleration vector at time $t$ . He experiences acceleration only in the downward direction because of gravity, and in particular $\vec a=-g\,\vec\jmath$ where $g=9.80\,\frac{\mathrm m}{\mathrm s^2}$ . Splitting up the position vector into components, we have $\vec r=r_x\,\vec\imath+r_y\,\vec\jmath$ with

$r_x=\left(3.5\,\dfrac{\mathrm m}{\mathrm s}\right)t$

$r_y=15.5\,\mathrm m-\dfrac g2t^2$

The Coyote hits the ground when $r_y=0$ :

$15.5\,\mathrm m-\dfrac g2t^2=0\implies t=1.8\,\mathrm s$

4b. Here we evaluate $r_x$ at the time found in (4a).

$r_x=\left(3.5\,\dfrac{\mathrm m}{\mathrm s}\right)(1.8\,\mathrm s)=6.3\,\mathrm m$

5. The shell has initial position vector $\vec r_0=(1.52\,\mathrm m)\,\vec\jmath$ , and we're told that after some time the bullet (now separated from the shell) has a position of $\vec r=(3500\,\mathrm m)\,\vec\imath$ .
