Question

Two blocks are sliding to the right across a horizontal surface, as the drawing shows. In Case A the mass of each block is 3.0 kg. In Case B the mass of block 1 (the block behind) is 6.0 kg, and the mass of block 2 is 3.0 kg. No frictional force acts on block 1 in either Case A or Case B. However, a kinetic frictional force of 5.8 N does act on block 2 in both cases and opposes the motion. For both Case A and Case B determine (a) the magnitude of the forces with which the blocks push against each other and (b) the magnitude of the acceleration of the blocks.

Answer 1

Answer:

Explanation:

According to a free body diagram the forces in the horizontal direction on body 1 would be:

F₁ = a₁*m₁ = -N

and on body 2:

F₂ = a₂*m₂ = N - F

N: normal force between the two blocks

F: frictional force on block 2

Since the two blocks are moving together, they need to have the same acceleration:

a₁ = a₂

This gives two equations with two unknown. Solving for a and N gives:

$a = - \frac{F}{m_1+m_2}$

$N = -am_1$

case A:

|a| = 0.96 m/s²

|N| = 2.9 N

case B:

|a| = 0.644 m/s²

|N| = 3.86 N
