Answer:
80.7lbft/hr
Explanation:
Flow rate of water in the system = 3.6x10^-6
The height h = 100
1s = 1/3600h
This implies that
Q = 3.6x10^-6/[1/3600]
Q = 0.0000036/0.000278
Q = 0.01295
Then the power is given as
P = rQh
The specific weight of water = 62.3 lb/ft³
P = 62.3 x 0.01295 x 100
P = 80.675lbft/h
When approximated
P = 80.7 lbft/h
This is the average power that could be generated in a year.
This answers the question and also corresponds with the answer in the question.
uniform
welcome 2 Ghana African state western region
solution from c hegg. hope it helps. see photos explanation
Answer:
a) I_LED= 1/6 A b) Vf= 2.5V
Explanation:
Consider circuit in the attachment.
a) We will simplify current source in paraller with resistor to a voltage source in series with a resistor(see attachment 2)
Solving the circuit in attachment 2 using mesh analysis
-9+2I1+4(I1-I2)-4+2I1=0
8I1 - 4I2= 13 ............... eq 1
4+4(I2-I1)+ I2 + 2=0
4I1- 5I2 = 6 ............ eq 2
I1= 41/24 ; I2 = 1/6; I2= I_LED
b) Solving the circuit in attachment 2 again, this time I2=0
8I1 - 4I2= 13
8I1- 4(0)=13
I1= 13/8
Vf= 4(I1- I2) -4
I2=I_LED=0
Vf= 2.5 V
