Question

A third point charge q3 is now positioned halfway between q1 and q2. The net force on q2 now has a magnitude of F2,net = 4.444 N and points away from q1 and q3. What is the value (sign and magnitude) of the charge q3?

Answer 1

Answer:

The value of third charge is 0.8μC.

Explanation:

Given that.

Magnitude of net force=4.444 N

According to figure,

Suppose, First charge = 2.4 μC

Second charge = 6.2 μC

Distance r₁ = 9.8 cm

Distance r₂ = 2.1 cm

We need to calculate the value of r

Using Pythagorean theorem

$r=\sqrt{(r_{1})^2+(r_{2})^2}$

Put the value into the formula

$r=\sqrt{(9.8)^2+(2.1)^2}$

$r=10.02\ cm$

We need to calculate the force

Using formula of force

$F_{12}=\dfrac{kq_{1}q_{2}}{(r)^2}$

Force F₁₂,

$F_{12}=\dfrac{9\times10^{9}\times2.4\times10^{-6}\times6.2\times10^{-6}}{(10.02\times10^{-2})^2}$

$F_{12}=13.33\ N$

$F_{21}=-13.33\ N$

Force F₂₃,

$F_{23}=\dfrac{9\times10^{9}\times6.2\times10^{-6}\times q_{3}}{(10.02)^2}$

We need to calculate the value of third charge

$F_{net}=F_{21}+F_{23}$

$4.444=-13.33+\dfrac{9\times10^{9}\times6.2\times10^{-6}\times q_{3}}{(5.01)^2}$

$q_{3}=\dfrac{(4.444+13.33)\times(5.01\times10^{-2})^2}{9\times10^{9}\times6.2\times10^{-6}}$

$q_{3}=7.99\times10^{-7}\ C$

$q_{3}=0.8\times10^{-6}\ C$

Hence, The value of third charge is 0.8μC.
